Rotating hollow handpieces

► Rotating hollow handpiece

Our special recommendation for polishing jobs (for example, when using rings for finishing). The hemisphere attached to the handle gives you a handrest while working and can be adapted for either right or left-handed users.

Easy chang between right and left-handed use!

Rotating hollow handpiece NHG-L

Order No. Price €

P ftmax 11,000 rpm

Telescopically extendable angle head (70 mm), with 125° head asjustment, anticlockwise rotation \ Collet WH

Y Speed max. 11,000 rpm

Dimensions 0 18x 190 mm (head 0 18x30 mm)

Weight 250 g

Accessories: Collet 0 3,0 mm, holderfor ring 0 12 mm,

tool set

0 031 400

Standard

0 031 400R

Rapid-Change

Rotating hollow handpiece NHK-L

Order No. Price €

P limax 12,000 rpm

telescopically extendable angle head (70 mm), with 125° head

asjustment, anticlockwise

Collet GH

Speed max. 12,000 rpm

Dimensions 0 18 x 215 mm (head 0 27 x 56 mm)

Weight 390 g

Accessories: Collet 0 6.0 mm, holder for ring 0 20 mm,

tool set

0 031 600

Standard

0 031 600R

Rapid-Change


		Order No. Price €
	Grip End Fits telescope handpieces with head NHG-R, NHG-L, NHK-R	0 031 499 Standard
	and upright telescopic ends	0 031 499R Rapid-Change

	Telescope piece with head NHK-R	0 031 498
	Clockwise, can be exchanged for handpiece NHG, including
	Collet 0 6.0 mm (type GH), max. speed: 11,000 rpm

	Telescope piece with head NHG-R	0 031 497
	Clockwise, can be exchanged for handpiece NHG-L, including
	Collet 0 3.0 mm (type WH), max. speed: 11,000 rpm

	Telescopic End, Set (in case), upright	0 031 700
	Consists of telescope piece, upright (Order No. 0031490),
	telescope handpiece, straight (Order No. 0031491) and Handle (Order No. 0031499)

	Telescope handpiece, straight (without Handle)	0 031 491
	with collet 0 6.0 mm (type GH), max. speed: 20,000 rpm

	Telescopic End, upright (without Handle)	0 031 490
	with collet 0 3.0 mm (type WH), max. speed: 20,000 rpm

Rotating hollow handpiece accessories

limax 11,000 rpm

lmax 11,000 rpm

P lmax 20,000 rpm
