NEW!
Diamond grinding points, solid tungsten carbide
shank 0 3 mm
Suitable for every measure
These grinding points are available in increments of 1/10 mm between 0.4 and 3.0 mm diameter. You are sure to find the right one for your application!
► D i amond grinding points, solid tungsten carbide
The new diamond grinding points made from solid tungsten carbide convince through their high rigidity and the resulting precise true running. They are available in ascending increments of 1/10 mm with a head diameter from 0.4 to 3.0 mm.
1
Head dimen-
Neck dimen-
Shank 0 x total
Grit
Order No.
Price €
Price €
sions D x T
sions d x L1
length
size
from 5 pieces
from 1 piece
0 0.4 x 2.0
0 0.3 x 3
0 3 x 40
D 54
0 560 051
0 0.5 x 2.0
0 0.4 x 3
0 3 x 40
D 64
0 560 052
0 0.6 x 3.0
0 0.5 x 5
0 3 x 40
D 64
0 560 053
0 0.6 x 3.0
0 0.4 x 5
0 3 x 40
D 91
0 560 054
0 0.7 x 3.0
0 0.6 x 6
0 3 x 40
D 64
0 560 055
0 0.7 x 3.0
0 0.5 x 6
0 3 x 40
D 91
0 560 056
0 0.8 x 3.0
0 0.7 x 6
0 3 x 40
D 64
0 560 057
0 0.8 x 3.0
0 0.6 x 6
0 3 x 40
D 91
0 560 058
0 0.9 x 3.0
0 0.8 x 7
0 3 x 40
D 64
0 560 059
0 0.9 x 3.0
0 0.7 x 7
0 3 x 40
D 91
0 560 060
0 1.0 x 3.0
0 0.8 x 7
0 3 x 40
D 76
0 560 061
0 1.0 x 3.0
0 0.7 x 7
0 3 x 40
D 107
0 560 062
0 1.0 x 3.0
0 0.7 x 7
0 3 x 40
D 151
0 560 063
0 1.1 x 3.0
0 0.9 x 8
0 3 x 40
D 76
0 560 064
0 1.1 x 3.0
0 0.8 x 8
0 3 x 40
D 107
0 560 065
0 1.1 x 3.0
0 0.8 x 8
0 3 x 40
D 151
0 560 066
0 1.2 x 3.0
0 1.0 x 8
0 3 x 40
D 76
0 560 067
0 1.2 x 3.0
0 0.9 x 8
0 3 x 40
D 107
0 560 068
0 1.2 x 3.0
0 0.9 x 8
0 3 x 40
D 151
0 560 069
0 1.3 x 3.0
0 1.1 x 8
0 3 x 40
D 76
0 560 070
0 1.3 x 3.0
0 1.0 x 8
0 3 x 40
D 107
0 560 071
0 1.3 x 3.0
0 1.0 x 8
0 3 x 40
D 151
0 560 072
0 1.4 x 3.0
0 1.2 x 8
0 3 x 40
D 76
0 560 073
0 1.4 x 3.0
0 1.1 x 8
0 3 x 40
D 107
0 560 074
0 1.4 x 3.0
0 1.1 x 8
0 3 x 40
D 151
0 560 075
0 1.5 x 3.0
0 1.3 x 15
0 3 x 40
D 76
0 560 076
0 1.5 x 3.0
0 1.2 x 15
0 3 x 40
D 107
0 560 077
0 1.5 x 3.0
0 1.2 x 15
0 3 x 40
D 151
0 560 078
0 1.6 x 4.0
0 1.4 x 15
0 3 x 40
D 76
0 560 079
0 1.6 x 4.0
0 1.3 x 15
0 3 x 40
D 107
0 560 080
0 1.6 x 4.0
0 1.3 x 15
0 3 x 40
D 151
0 560 081
0 1.7 x 4.0
0 1.5 x 15
0 3 x 40
D 76
0 560 082
0 1.7 x 4.0
0 1.4 x 15
0 3 x 40
D 107
0 560 083
0 1.7 x 4.0
0 1.4 x 15
0 3 x 40
D 151
0 560 084
Diamond grinding points, solide tungsten car­bide, galvanic bonding, shank 0 3 mm
3
Cylinder
d
1 All measurements in mm
