507 8 Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 8. Workplace systems // 8.1. Workshop equipment Optional pivot unit for installation on JOKE® Ergo-Work worktable Order No. Price DS 300 clamping table 0 200 300-1 Rotation range 360° manual Pivot range 0 - 100° through gearing mechanism Weight approx. 48 kg Accessories Mounting plate Ø 300 mm with grid holes M10 and receiving holes for magnets JOKE® easy-Work positioner with magnet Ø 125 mm 0 200 860 Rotation range 360° manual Pivot range 0 - 90° manual Dimensions (W x H x D) 150 x 160 x 150 mm Clamping system Magnet Ø 125 mm JOKE® easy-Work positioner with T-slot mounting plate, round 0 200 861 Rotation range 360° manual Pivot range 0 - 90° manual Dimensions (W x H x D) 250 x 130 x 250 mm Clamping system T-slot mounting plate, Ø 248 mm Optional accessories for JOKE® Ergo-Work worktable Order No. Price Hand switch 0 200 852 to control horizontal movement, incl. 1 m cable Foot switch 0 200 853 to control horizontal movement by foot, incl. 1 m cable Control cabinet 0 200 854 with integrated controls and 6 power sockets, incl. fixed foot switch Connector strip (5 x) 2017751 Storage table 0 200 856 incl. cross clamping unit, height adjustment, stainless steel pipe and tray Left-hand storage column 0 200 855 incl. attachment base and stainless steel pipe Right-hand column for hanging motor 0 200 857 incl. attachment base and stainless steel pipe Arm for hanging motor 0 200 858 incl. cross clamping unit, height adjustment, stainless steel pipe and holder for hanging motor Illuminated magnifying glass, ready to use 0 200 560 Worktable JOKE® Ergo-Work Accessories • Pivot units Abb. inkl. T-Nutenplatte Ø 248 mm
