560 8 i Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 8. Workplace systems // 8.4. Inspection tools Inspection system Heine Beta 200 Light heads Illuminated magnifying glass head (without clip-on magnifying glass) Order No. Price This robust all-metal clip-on tool with 3.5 V halogen lamp provides a particularly bright, white light. It is particularly suited to stationary use, but also small enough to fit into a pocket. Direction of view 0°, max. distance to object: 70 mm. Suitable for all beta battery handles. Magnification 3 – 4 x. 0 203 073 Accessories / spares Order No. Price Mirror attachments 90° - Ø 5 mm, length 25 mm 0 203 075 Mirror attachments 90° - Ø 6 mm, length 30 mm 0 203 016 Mirror attachments 90° - Ø 6 mm, length 50 mm 0 203 076 Swivelling magnifying glass 0 203 029 Spare halogen lamp, 3.5 V 0 203 074 Functional principle The light of a lens bulb is projected onto the end surface of a bundle of optical fibres consisting of several thousand optical fibres. The fibres are arranged in a circle at the point of emergence of light . Uniform and shadow-free coaxial illumination of the field of observation is produced in this manner. Viewing direction 0° Viewing direction 90° For corresponding power supplies, see page 537
