506 8 Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 8. Workplace systems // 8.1. Workshop equipment Worktable JOKE® Ergo-Work Basic modules Worktable JOKE® Ergo-Work Maximum flexibility thanks to the modular system. The JOKE® Ergo-Work worktable can be perfectly adjusted to your requirements – simply choose the accessories you need to create your perfect workplace. The vertically adjustable worktop (max. 355 mm) made from milled aluminium or powder-coated steel, forms the basis of this system. All the optional accessories can be attached to this table: From tool holders for the ENESKA systems and the JOKEFLEX® motor unit to illuminated magnifying glasses to give you the perfect view of your workpiece. Everything fits perfectly to the worktable, which can be set to the desired height either via hand or foot switch. There are two rotating and reversible clamps available for the retention of workpieces: The DS 300 clamping table provides a firm grip for large, heavy workpieces whilst the easy-Work clamp hold light to medium-weight workpieces. Furthermore, the worktop can be fitted with a conventional bench vice or another rotating and reversible clamping device as well as the new JOKE® arm rest (see page 509). Highlights: • Perfect working position thanks to electric height adjustment • Modular system guarantees maximum flexibility • Large range of accessories Illustr. incl. accessories Worktable JOKE® Ergo-Work Basic modules Version Order No. Price with steel tabletop 0 200 850 with aluminium tabletop 0 200 851 Dimension (B x H x T) 970 x 1.600 x 680 mm Dim. tabletop (B x H x T) 950 x 500 mm Height adjustment 695 to 1.050 mm, continuously adjustable Max. load 200 kg (at the centre of the worktop) Supply voltage 230 V, 50/60 Hz Connected load 400 W (excl. accessories) Scope of delivery Excl. accessories and pivot unit
