540 8 Inno-Check ƒô ƒô ƒô ƒô 8. Workplace systems // 8.3. Microscopes and control tools Cold light source ECO 20 W Universal workplace lighting with magnetic foot and XXL swan neck Cold light sources The cold light source is used for ultra-precise illumination of workpieces and surfaces etc. by means of the flexible glass fibre light guides. The incident light does not generate any heat (= cold light) and its diffusion is absolutely uniform. This simultaneously prevents a possible change in colour of the objects observed. The self-supporting, flexible and rigid light guide allows the light to be aimed easily at the desired spot. The cold light lamp is used to facilitate optical inspection/control of workpieces/surfaces performed using microscopes, magnifying glasses, etc. Cold light source ECO 20 W Order No. Price Cold light source 20 W halogen with single swan-necked light guide, 45 cm 0 200 750 Lamp 12 V with base GU 5.3/5 l mm Colour temperature 3,100 K Bulb life approx. 4000 h Luminance On/Off switch Cooling none Dimensions (W x H x D) approx. 80 x 115 x 200 mm Supply voltage 230 V, 50/60 Hz Fuse 1 A slow-blow Protection category IP 20 Net weight approx. 1.9 kg Weight with light guide approx. 2.2 kg Spare parts/accessories ECO 20 W Order No. Price Halogen lamp, 20 W 0 200 751 Single swan-necked light guide, 55 cm 0 200 730 Double swan-necked light guide, 55 cm 0 200 720 Magnetic foot with switch for positioning on the workpiece can be flexibly used in large moulds XXL swan necks (each 800 mm) compatible with all JOKE® cold light sources magnetic foot for rapid fixing Universal workplace lighting Order No. Price for direct connection to our cold light sources. Delivery incl. magnetic foot for positioning on the workpiece in addition to two XXL swan necks (each 800 mm) and a flexible fibre optic supply lead (2000 mm) 0 200 778 XXL swan necks smallest bending radius 55 mm! NEW!
