536 8 i Bestseller! Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 8. Workplace systems // 8.3. Microscopes and control tools Stereomicroscopes SM-100 • SM-200 Stereomicroscopes Our stereomicroscopes are used to visually magnify workpieces or their surfaces for observation and inspection. Furthermore, tasks such as microwelding or polishing work can be monitored and checked in terms of quality directly at the workpiece. You have the choice between the introductory model SM-100 and the thousand times over tried and trusted top model SM-200 with versatile possibilities. The structure of the stereomicroscopes with two eyepieces and one lens allows threedimensional representation of the surface observed. Consequently, differences in height on the observation level can in particular be plastically detected. Stereomicroscope SM-200 The universally on columns pivoting and displaceable stereomicroscope can also be optimally erected over large workpieces without having to align the workpiece accordingly. The inspection area can be evenly illuminated by means of a ring light attachable to the lens. The optimum magnification can be arranged using eyepieces and lenses with different magnifying factors. Stereomicroscope SM-100 The little brother of the large microscope SM-200 is already equipped as standard with a camera barrel. Otherwise this microscope offers sophisticated technology too at an introductory price. The light can be switched separately with 3 versions: either only incident light or only transmitted light in addition to a combination of incident light and transmitted light. The ideal basis for a digital image archiving environment: it is possible to switch over as desired from a stereo view through the eyepieces to camera deployment. In this case, the object is only still visible in one eyepiece. By substituting the glass plate supplied for the black/white working plate, it is also possible to observe objects with the transmitted light method. Microscope equipment Magnification SM-100 Magnification SM-200 Visible field Ø Working distance Eyepiece 10 x and lens 0.5 x 5 – 20 x 3.25 – 22.5 x Ø 8 – 54 mm 160 mm Eyepiece 25 x and lens 0.5 x 12.5 – 50 x 8.125 – 56.25 x Ø 5.3 – 30 mm Eyepiece 10 x and lens 0 x 10 - 40 x 6.5 – 45 x Ø 4 – 27 mm 90 mm Eyepiece 10 x and lens 2 x 20 – 80 x 13 - 90 x Ø 2.6 – 18 mm Eyepiece 25 x and lens 0 x 25 - 100 x 16.25 – 112.5 x Ø 2 – 13 mm 25 mm Eyepiece 25 x and lens 2 x 50 – 200 x 32.5 – 225 x Ø 1.3 – 7 mm SM-200 with camera barrel Visible field Ø and working distance depending on the magnification The stereomicroscope SM 100 is already equipped with a camera barrel as standard and is therefore ideal as the basis for digital image archiving! The stereomicroscope SM-200 is capable of versatile pivoting and displacement by means of columns and may therefore be erected over large workpieces.
