529 8 Bestseller! Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 8. Workplace systems // 8.1. Workshop equipment Suction device with initial filter equipment and filter monitoring, continuously adjustable, operating hour counter, 4 castors for mobile use, without accessories Technical data: Suction capacity, free-blowing 320 m³/h Suction capacity, effective 30 - 280 m³/h Max. compression 21,000 Pa Motor constant running Connection 230 V, 50/60 Hz Motor output 1.1 kW Noise level approx. 62 dB(A) Gewicht approx. 40 kg Dimensions (W x H x D) 350 x 700 x 350 mm (with activated charcoal filter: 350 x 930 x 350 mm) Colour RAL 7035 Suction connectors 3 (rear) Suction connectors for arm 1 (top) Filter equipment Suspended matter filter H 13 2.4 m2 + z-line filter (Order No. 0 200 250-1), activated charcoal filter + suspended matter filter + z-line filter (Order No. 0 200 250-ZA) Suction unit JOKE® AFD Premium Suction unit JOKE® AFD Premium Version Order No. Price with suspended matter filter 0 200 250-1 with activated charcoal filter 0 200 250-ZA Replacement filters Order No. Price Suspended matter filter, 300 x 300 x 78 mm 0 200 246 Z-line filter, 300 x 300 x 145 mm (packing: 3 pieces) 0 200 245 Activated charcoal filter, 295 x 295 x 20 mm 0 200 240-1 Accessories Order No. Price Suction arm for mounting on device 0 200 266 850 mm long, 3 articulations, with damper cap, anodised aluminium tubes Suction arm for table mounting 0 200 268 850 mm long, 3 articulations, with damper cap, anodised aluminium tubes, including table bracket and 2.5 m hose Tube nozzle for suction arm 0 200 243 310 mm long, anodised aluminium Suction hood for suction arm 0 200 248 Ø 200 mm Connecting hose NW44 0 200 247 2.5 m incl. 2 connecting sleeves Fig. shows model with z-line filter
