528 8 Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 8. Workplace systems // 8.1. Workshop equipment Suction unit JOKE® AFD Compact Suction unit JOKE® AFD Compact Version Order No. Price with suspended matter filter 0 200 230-1 with activated charcoal filter 0 200 230-ZA Replacement filters Order No. Price Suspended matter filter H13, 250 x 250 x 190 mm 0 200 271 Filter mats F5, 230 x 230 mm (packing: 20 pieces) 0 200 257 Combination filter suspended matter/activated charcoal, 250 x 250 x 190 mm 0 200 240-4 Accessories Order No. Price Suction arm for mounting on device 0 200 242-3 850 mm long, 3 articulations, without damper cap, anodised aluminium tubes Suction arm for table mounting 0 200 268 850 mm long, 3 articulations, with damper cap, anodised aluminium tubes, including table bracket and 2.5 m hose Tube nozzle for suction arm 0 200 243 310 mm long, anodised aluminium Suction hood for suction arm 0 200 248 Ø 200 mm Connecting hose NW44 0 200 247 2.5 m incl. 2 connecting sleeves Suction device with initial filter equipment, continuously adjustable, operating hour counter, 4 castors for mobile use, without accessories Technical data: Suction capacity, free-blowing 220 m³/h Suction capacity, effective 30 - 150 m³/h Max. compression 13,000 Pa Motor constant running Connection 230 V, 50/60 Hz Motor output 1.1 kW Noise level approx. 50 dB(A) Gewicht approx. 27 kg Dimensions (W x H x D) 290 x 560 x 290 mm Colour RAL 7035 Suction connectors 2 (rear) Suction connectors for arm 1 (top) Filter equipment Prefilter F5 + suspended matter filter H 13 (Order No. 0 200 230-1) Prefilter F5 + suspended matter filter H13 + activated charcoal filter (Order No. 0 200 230-ZA) NEW!
