527 8 i Bestseller! Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 8. Workplace systems // 8.1. Workshop equipment Suction units JOKE® AFD … Laser emissions, dust and fine particles, solvents, adhesive vapour, solder vapour/ welding vapour … at least one of these or some other pollutions also occur daily in your working environment. You should do something about them in order to avoid damage to health. With a suction unit from JOKE®, you create the optimum conditions for “good air” at the workplace – even if you ever “let it fly”. With us, you have a choice between two suction systems: • AFD Compact as an economically-priced introductory system • AFD Premium as a highly efficient system with comprehensive equipment details (high filter capacity, filter monitoring, serial interface for remote control) Both systems can be configured with two filter modules. Suspended matter filter for dusts/fine particles and all particles that arise in mechanical processing sequences. The activated charcoal filter is used wherever solvents, adhesive vapours, soldering vapour, smoke and similar gaseous pollutions arise. It eliminates or reduces them to a minimum. Owing to the high density of the filters used, a very high level of separation of the particles and contaminants to be aspirated is achieved. The filters can be combined as individual modules and are easy to replace. Consequently, if replacement is required, you only actually need to change the saturated filter, whereas the remainder can continue to be used. The turbine cooling (bypass cooling) inside the devices ensures very long services lives of the turbine units, even during constant use. The modular construction allows effective adaptation to individual requirements. Suction units Overview Aerolsols consist of a large number of dust and smoke particles of different diameters. They occur during production processes such as milling, drilling, laser work, cutting, soldering and engraving, etc. The particle size is indicated in micrometres (ìm = 10-6mm). Contamination of the respiratory tracts depending on the particle size is shown in the diagram opposite. Maintenance intervals of the filters With a properly dimensioned unit, the following intervals result for the individual filter types, depending on the contamination: • Z-line filter: 4 - 8 months • suspended matter filters: 4 - 8 months • activated charcoal filters: 6 - 12 months Without a change of filter, no protection of your health exists! Nasal mucosa and pharynx 10 ìm Larynx 4.7 - 5.8 ìm Trachea and main bronchi 3.3 - 4.7 ìm Secondary and terminal bronchi 1.1 - 3.3 ìm Lung heavily contaminated (without filter suction) Alveoli 1 ìm Things to know about contaminants at the workplace and use of suction units Suction hood Order No. 0 200 248 Suction tube Order No. 0 200 243 Suction arm for table mounting Order No. 0 200 268 Suction arm for mounting on device Premium Order No. 0 200 266 Compact Order No. 0 200 242-3 Suction unit Premium Order No. 0 200 250-1 Compact Order No. 0 200 230-1 Fig. AFD premium model
