512 8 Bestseller! Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 8. Workplace systems // 8.1. Workshop equipment Clamping table JOKE® DS 300 Clamping table JOKE® DS 300 Workpieces of up to 200 kg can be clamped with the DS 300 clamping table, pivoted within a range of 0 to 100° and rotated by 360° on the turntable. The turntable locking and self-locking pivoting drive ensure a secure hold of the workpiece in any working position. The grid bore support plate with M10 tensioning medium can be used to clamp any workpiece. A selection of different magnetic chucks is available for the clamping table. JOKE® DS 300 clamping table Order No. Price With Ø 300 mm support plate to hold different magnetic chucks. Grid holes M10 4 x 90° for mechanical clamping without magnetic chucks. Dimensions Base plate 540 x 420 mm Height Turntable ca. 130 mm Weight 63 kg 0 200 300 Tensioning media for threaded plates Order No. Price M 10 octagonal block 0 200 888 adjustable in 3 mm intervals, height: 10 mm M 10 excentric clamp 0 200 305 Excentric travel: 6 mm, height: 12 mm Round magnets for JOKE® DS 300 clamping table Dimensions mm Weight Clamping force Pole pitch Order No. Price Ø 160 x 75 9 kg 120 N/cm² 6 + 1.5 + 2 +1.5 0 200 314 Ø 200 x 80 13 kg 120 N/cm² 8 + 5 0 200 313 Ø 250 x 80 20 kg 120 N/cm² 8 + 5 0 200 312 Ø 300 x 85 mm 29 kg 120 N/cm² 8 + 5 0 200 310
