new!

TIG welding fillers

JOKE® Fill


Welding filler JOKE® Fill 120 - TIG	Design	Dimensions	Weight	Order No.	Price €
For compounds and intermediate layers on hot-	Rod 500 mm	0 0.8 mm	500 g	0 084 081
work and stainless steels. Structure: tough, elastic, corrosion-, acid and crack-proof, erodible. Not heat treatable, nitrable or chrome platable.		0 1.0 mm	1.000 g	0 084 082
		0 1.2 mm	1.000 g	0 084 083
		0 1.6 mm	1.000 g	0 084 084

Base composition %: C 0.02 • Cr 19.50 • Fe 1.90 • * pl_us _an₀y _surch_arg_e

Mn 2.80 • Si 0.20 • Nb 2.50 • Ni remainder

Suitable for material Nos.: various


Welding filler JOKE® Fill 125 - TIG	Design	Dimensions	Weight	Order No.	Price €
Filler for hot-work steels. Heat treatable and an-	Rod 500 mm	0 0.8 mm	500 g	0084101
nealable similar to parent material. Structurally synchronous or similar to many hot-work steels. Tension-regulating in the Martensite area. Chrome platable. Hardness of weld metal 34 to 42 HRC,		0 1.0 mm	1.000 g	0084102
		0 1.2 mm	1.000 g	0084103
		0 1.6 mm	1.000 g	0084104

depending on composition of parent materials. * pl_us _an_oy _surcharg_e

Hardenable to ca. 58 HRC.

Base composition %: C 0.40 • Al 0.03 • Cr 5.00 • Mn 0.33 «Mo 1.15 • Si 1.10 • V 0.41 • W 0.42 • Fe remainder

Suitable for material No.

1.2343 • 1.2344 • 1.2360 • 1.2362 and similar


Welding filler JOKE® Fill 140 - TIG	Design	Dimensions	Weight	Order No.	Price €
High-alloy Cr-Co-Mn-Mo-W-Fe welding filler with	Rod 500 mm	0 0.8 mm	500 g	0084 121
universal characteristics for use on case-hardened, heat-treated and hot-work steels. Corrosion, acid-and tinder-proof. Good surface-fusing with nitrated steels. Not chrome platable and nitrable.		0 1.0 mm	1.000 g	0084 122
		0 1.2 mm	1.000 g	0084 123
		0 1.6 mm	1.000 g	0084 124

* plus alloy surcharge

Base composition %: C 0.03 • Cr 19.00 • Fe 2.10 • Mn 3.00 • Si 0.30 • Nb 3.00 • Ni remainder

Suitable for material Nos.

1.2713 • 1.2343 • 1.2767 and similar

Welding filler JOKE® Fill 145 - TIG

Air hardening characteristics of 48 - 56 HRC. Etchible, erodible and polishable. Chrome platable and coatable. Note: thermic normalisation.

Base composition %: C 0.35 • Al 0.03 • Cr 5.30 • Mn 0.60 • Mo 1.50 • Si 0.70 • V 0.80 • W 040 • Fe remainder

* plus alloy surcharge

Suitable for material Nos.

1.2343 • 1.2344 • 1.2362 • 1.2363 • 1.2367 and similar
