NEW!

Laser welding fillers

JOKE® Fill


Welding filler JOKE® Fill 125 - Laser	Design	Dimensions	Weight	Order No.	Price €
Cr-Mo-Mn-Vanadine filler for hot-work steels. Pol-	Spool 50 g	0 0.25 mm	50 g	0084 112
ishable, erodible, nitritable, etchible and heat treatable. Can be hardened to ca. 58 HRC. For plastic, blowing and injection moulds. Readily machinable. Shock-temperature resistant.		0 0.3 mm	50 g	0084 113
		0 0.4 mm	50 g	0084 114
		0 0.5 mm	50 g	0084 115
Hardness first layer: ca. 46-52 HRC.		0 0.6 mm	50 g	0084 116
Hardness first layer: ca. 46-52 HRC.
Base composition %: C 0.40 • Al 0.03 • Cr 5.00 •	Spool 150 g	0 0.25 mm	150 g	0 084 112-2
Mn 0.33 «Mo 1.15 • Si 1.10 • V 0.41 • W 0.42 • Fe		0 0.3 mm	150 g	0 084 113-2
remainder		0 0.4 mm	150 g	0 084 114-2
Suitable for material		0 0.5 mm	150 g	0 084 115-2
No. 1.2343 • 1.2344 • 1.2360 • 1.2362 and similar		0 0.6 mm	150 g	0 084 116-2

	Spool 500 g	0 0.25 mm	500 g	0 084 112-4
		0 0.3 mm	500 g	0 084 113-4
		0 0.4 mm	500 g	0 084 114-4
		0 0.5 mm	500 g	0 084 115-4
		0 0.6 mm	500 g	0 084 116-4

	Rod 300 mm	0 0.3 mm	150 g	0 084 113-7
		0 0.4 mm	150 g	0 084 114-7
		0 0.5 mm	150 g	0 084 115-7
		0 0.6 mm	150 g	0 084 116-7
Welding filler JOKE® Fill 140 - Laser	Design	Dimensions	Weight	Order No.	Price €
High-alloy Co-Cr-Mo-Mn-W-Fe filler for many heat-	Spool 50 g	0 0.1 mm	50 g	0084 131
treated, case-hardened and heat resistant steels with universal characteristics. Suitable for nitrided steels, edge- and acid-proof. Not chrome platable. Polishable, but only delayed erodible. Structure		0 0.2 mm	50 g	0084 132
		0 0.3 mm	50 g	0084 133
		0 0.4 mm	50 g	0084 134
thermally very resistant.		0 0.5 mm	50 g	0084 135
Hardness first layer: ca. 24-36 HRC. Through artificial ageing and pressure/impact, the hardness can		0 0.6 mm	50 g	0084 136

be enhanced by up to 35 %! Expansion ca. 18-25 %.	Spool 150 g	0 0.1 mm	150 g	0 084 131-2
Base composition %: C 0.03 • Cr 19.00 • Fe 2.10 • Mn 3.00 • Si 0.30 • Nb 3.00 • Ni remainder		0 0.2 mm	150 g	0 084 132-2
		0 0.3 mm	150 g	0 084 133-2
		0 0.4 mm	150 g	0 084 134-2
Suitable for material Nos.: Various		0 0.5 mm	150 g	0 084 135-2
		0 0.6 mm	150 g	0 084 136-2

	Spool 500 g	0 0.1 mm	500 g	0 084 131-4
		0 0.2 mm	500 g	0 084 132-4
		0 0.3 mm	500 g	0 084 133-4
		0 0.4 mm	500 g	0 084 134-4
continued on page 402		0 0.5 mm	500 g	0 08 4135-4
		0 0.6 mm	500 g	0 084 136-4
