166
2
Tel. +49 (0) 22 04 / 8 39-0 Fax +49 (0) 22 04 / 8 39-61 info@joke.de
2. Grinding and polishing tools // 2.4. Polishing brushes and buff wheels
Compact fleece discs
Convolute Wheels Series 500 Series 600
Convolute Wheels
During manufacture of the convolute
wheels, fleece fibre nylon is impregnated
with an abrasive grit and is wound around
a hard carrier core. The individual layers
are laced with an adhesive in order to
provide a uniform pattern that must be
observed for the direction of rotation.
Applications:
removal of burs
deburring of stainless steel pipe threads
deburring of die-cast aluminium burs
Advantages:
long service life
less edge wear
dust-free
fatigue-free work
no smearing
Highly compressed compact discs, series 500 and 600
Manufactured from highly compressed, high quality fleece material. They offer a unique
structure with high quality stock removal and excellent finishing quality. The direction
of rotation is of no importance for these discs!
Series 500
Applications:
general cleaning tasks
removal of thermal discoloration
removal of coatings
processing of turbine blades
Advantages:
high strength
high edge stability
adaptation to the workpiece
metal-free
versatile in use
no clogging
Series 600
Applications:
facing and finishing of turbine blades
and stainless steel surgical instruments
removal of small surface lesions
finishing of implants
Advantages:
high strength
high edge stability
adaptation to the workpiece
metal-free
versatile in use
no clogging
matching mounting shank: order no. 0 545 183
matching reducing rings: order no. 0 571 406
order no. 0 571 407
NEW!
Compact fleece discs Dimensions mm Grit Hardness Abrasive Drilling mm Order No. Price
Convulute Wheels Ψ 152 x 13 8 S Fine Medium Silicon carbide 25 0 430 003
Ψ 152 x 25 8 S Fine Medium Silicon carbide 25 0 430 004
Series 532 Ψ 76 x 6 Fine Soft Silicon carbide 6 0 430 005
Ψ 76 x 13 Fine Soft Silicon carbide 6 0 430 008
Series 632 Ψ 76 x 6 Fine Medium-hard Silicon carbide 6 0 430 007
Ψ 76 x 13 Fine Medium-hard Silicon carbide 6 0 430 006
