98 2 Bestseller! Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 2. Grinding and polishing tools // 2.1. Compounds and fluids Step 1 - grinding Step 1 - lapping Initial surface Step 2 - lapping Step 5 - wiping Step 4 - polishing Step 4 - polishing Step 3 - polishing Step 3 - polishing ground or Magic LAP + JOKE® Magic diamond compound 6 or 9 ìm , concentr. high, with 4 drops of diamond fluid Stroke length: 1.5 mm No. of strokes: 2500/min Magic LAP + JOKE® Magic diamond compound 14 or 25 ìm concentration: high, with 4 drops of diamond fluid Stroke length: 1.5 mm No. of strokes: 2500/min Magic Stone up to grit size 600 POLISHING WITH JOKE® MAGIC PREPARATION JOKE® Magic very fine polishing suspension 1 ìm with polishing cloth Magic Clean Wooden lapping stick + JOKE® Magic diamond compound 6 ìm concentration: extra strong, with 2 drops of diamond fluid Stroke length: 1.5 mm, no. of strokes: 9500/min JOKE® Magic felt + JOKE® Magic diamond compound 6 ìm concentration: extra strong, with 2 drops of diamond fluid Stroke length: 1.5 mm, no. of strokes: 9500/min JOKE® Magic felt + JOKE® Magic diamond compound 6 or 9 ìm, concentration: extra strong, with 2 drops of diamond fluid Speed: 9000 rpm JOKE® Magic felt + JOKE® Magic diamond compound 3 ìm concentration: extra strong, with 2 drops of diamond fluid Speed: 9000 rpm Further processing linear Further processing rotating JOKE® Magic Polishing method for steel processing
