Untitled


	Technical data	FERMANT® 40 NC-LH	FERMANT® 60 NC-LH
	Order no.	2 017 590	2 017 506
	Sealing length	400 mm	600 mm
	Sealing width	4 mm	4 mm
	Bar opening	25 mm	25 mm
	Bar range of action	40 mm	40 mm
	Max. sealing output	2 x 0.4 mm PE film	2 x 0.4 mm PE film
	Actucation	foot control and hand lever	foot control and hand lever
	Impulse time	digitally selectable	digitally selectable
	Coolig time	digitally selectable	digitally selectable
	Degree of protection	IP 20	IP 20
	Dimensions (W x H x D)	700 x 330 x 220 mm	900 x 330 x 220 mm
	Weight	45 kg	69 kg
	Connected voltage	230 V, 50/60 Hz	230 V, 50/60 Hz
	Fuse	16 A, slow-blow	16 A, slow-blow

M O)

"> 0}

-a

a>

M

E

Technical and design modifications reserved

The advantages at a glanée

• universally usable for the most diverse types of film

• low noise emission of the suction device

• easy and safe operation of the suction device

• high aspiration power of the suction device

• films can also be sealed without air suction

• manual cutting device behind the sealing bars

This clamping bar secures bags during air extraction and prevents inflow of air

C

Accessories

• Support table for improved guiding of the bag (Order no. 2 010 633)

Manual cutting device

Support table for improved guiding of the bag

Reduced-volume packed small items

Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-13 • info@joke.de

31
