13 1 Ø 21,5 Ø 20 62 Ø 20 88 91 20 Ø 13 Ø 20 22 27 „¯ 27 „¯ nmax 30.000 1/min nmax 20.000 1/min Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 1. Driving motors and handpieces // 1.2. Electric motor systems Handpiece VH-E Order No. Price For connection to micromotor NCL-25-SS Collet CHH (Ø 2.35 and Ø 3.0 mm when delivered) Rotation speed max. 30,000 rpm Dimensions Ø 20 x 88 mm Weight 80 g 0 009 715 Micromotor NCL-25-SS Order No. Price For operation of ENESKA 1 handpieces Rotation speed range 2,000 - 30,000 rpm Output 35 W Dimensions Ø 62 x 21.5 mm (without thread) Weight 100 g 0 009 711 Angle handpiece JKC-C 345 Order No. Price For connection to micromotor NCL-25-SS Collet CHC (Ø 3,0 mm when delivered) Rotation speed max. 20,000 rpm, no reverse rotation Dimensions Ø 20 x 91 mm Weight 60 g 0 009 716 Mobile grinding, milling and polishing system ENESKA 1 Collets, rapid-chuck handpiece VH-E Type Dimensions Order No. Price CHH Ø 0.5 mm 0 009 154 5 Ø 0.8 mm 0 009 154 Ø 1.0 mm 0 009 155 Ø 1.5 mm 0 009 156 Ø 1.6 mm 0 009 157 Ø 2.0 mm 0 009 158 Ø 2.35 mm 0 009 152 Ø 2.5 mm 0 009 159 Ø 3.0 mm 0 009 151 Ø 1/8“ 0 009 153 Collets angle handpiece JKC-C 345 Type Dimensions Order No. Price CHH Ø 1.6 mm 0 009 207 Ø 2.35 mm 0 009 202 Ø 3.0 mm 0 009 201 Ø 1/8“ 0 009 203 find the Overview of suitable collets on page 27! page: find the Overview of suitable collets on page 27! page: 574,00 383,00 304,00 198,00 198,00 94,75 94,75 59,20 94,75 59,20 94,75 59,20 59,20 59,20 59,20 59,20 59,20
