12 1 Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 1. Driving motors and handpieces // 1.2. Electric motor systems Mobile grinding, milling and polishing system ENESKA 1 Complete Set ENESKA 1 Order No. Price The set comes in a plastic case and contains: 1 x control unit NE-77A (Order No. 0 009 713-0) 1 x micromotor NCL-25-SS (Order No. 0 009 711) 1 x tray (Order No. 0 009 712-0) 1 x rapid-chuck handpiece VH-E (Order No. 0 009 715) including collets 2.35 and 3.0 mm 1 x charger NE-106-03 (Order No. 0 009 714-0) 1 x handpiece receptacle (Order No. 0 009 004) 0 009 700-0 Control unit NE-77A Order No. Price Continuous rotation speed adjustment 2,000 - 30,000 rpm Efficient NiCad battery for mobile operation (approx. 1 hour charging time / 1 hour continuous operation) Left / right operation Hand / foot operation Dimensions (w x h x d) 72 x 163 x 95 mm Weight 400 g Output voltage 10 V DC 0 009 713-0 Accessories ENESKA 1 Order No. Price Motor cable NCL-25-CD-V 0 009 712-0 To connect micromotor NCL-25-SS with control unit NE-77A, length: 0.6 - 1.5 m (spiral cable), weight: 57 g Charger NE-106-03 0 009 714-0 For recharging control unit battery NE-77A, Supply: 230 V, 50/60 Hz Foot switch FC 25 0 009 701 Foot can be used to adjust rotation speed and start/stop ENESKA 1 - Performance in a pocket format Compact, handy system with battery operation. The ENESKA 1 can be used anywhere where the workpiece is hard to get at or would need to be removed from the production line at great time cost. Its compact case contains mature technology, based on the tried and tested “big” ENESKA 3-1-System. The micromotor can optionally be fitted with either a rapidchuck handpiece or an angle handpiece. 1.190,00 299,00 66,20 104,50 63,50
