74 1 P 320.000 1/min Inno-Check ƒô ƒô ƒô ƒô Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 1. Driving motors and handpieces // 1.4. Pneumatic drive systems High-speed handpiece ENESKA P 320-2 High-speed handpiece ENESKA P 320 The virtuoso among our handpieces. This handpiece can be used for the highest precision jobs anywhere; for example, when deburring steel, stainless steel or even glass and plastics. Thanks to its compact, ergonomic and – due to its aluminium casing - very light design, the handpiece fits perfectly in your hand and can be held like a pen. This means that the user can work even for longer periods without tiring. Changing tools takes just seconds, thanks to the Quick-Change mechanism: Twist, take out old tool, click in new tool, that’s it. Maintenance unit in new design Optimised noise development Complete set with all accessories Highest rotational speed: 320,000 rpm High-speed handpiece ENESKA P 320-2 Order No. Price Speed max. 320,000 1/min Air pressure 2.5 bar Air consumption 40 l/min Noise level < 75 dB(A) at 320,000 rpm Dimensions Ø 16 x 130 mm Weight 71 g Accessories 2 m air line and collet Ø 1.6 mm 0 009 901 Set: ENESKA P 320-2 Order No. Price Complete set incl. handpiece including collet Ø 1.6 mm, 2 m air line and connection, maintenance unit, foot switch and connecting accessories (3-part) Dimensions (W x H x D) 115 x 160 x 100 mm Weight 2.35 kg 0 009 900-0 Spares/accessories Order No. Price Collet 1.6 mm 0 009 909 Head, complete (spare) 0 009 902 including collet NEW! 690,00 795,00 36,35 165,00
