56 1 132 Ø 24 nmax 18.000 1/min Ø17 30 Ø 24 Ø 24 Ø 24 175 180 180 Ø17 Ø 30 nmax 18.000 1/min nmax 18.000 1/min nmax 18.000 1/min Ø24 43 171 nmax 18.000 1/min Bestseller! Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 1. Driving motors and handpieces // 1.3. Flexible shaft systems Handpieces JOKE® Classic-Line Handpiece THSZ/N Order No. Price Collet GH (Ø 3 mm when delivered) Speed max. 18,000 1/min Dimensions Ø 24 x 132 mm Weight 120 g Accessories wrench, clamping pin 0 030 004 Handpiece VTN-N 0° Order No. Price 70 mm telescope-type extendable angle head with straight 0° head adjustment, clockwise rotation Collet WH (Ø 3.0 mm when delivered) Speed max. 18,000 1/min Dimensions Ø 26 x 136 mm (head Ø 17 x 30 mm) Weight 185 g Accessories tool kit 0 031 347 Angle-handpiece VTN-N 90° Order No. Price 70 mm telescope-type extendable angle head with 90° head adjustment, clockwise rotation Collet WH (Ø 2.35 und Ø 3.0 mm when delivered) Speed max. 18,000 1/min Dimensions Ø 24 x 175 mm (head Ø 17 x 30 mm) Weight 185 g Accessories tool kit 0 031 341 Angle-handpiece VTN-N 135° Order No. Price 70 mm telescope-type extendable angle head with 135° head adjustment, anticlockwise rotation Collet WH (Ø 2.35 und Ø 3.0 mm when delivered) Speed max. 18,000 1/min Dimensions Ø 24 x 180 mm (head Ø 17 x 30 mm) Weight 185 g Accessories tool kit 0 031 342 Angle-handpiece VTN-S/N Order No. Price Collet GH (Ø 3 and Ø 6 mm when delivered) Speed max. 18,000 1/min, clockwise rotation Dimensions Ø 24 x 171 mm (head Ø 24 x 51 mm) Weight 240 g Accessories: Tool set 0 031 540 0 030 004R 0031347R 0 031 341R 0 031 342R 0 031 540R Standard Rapid-Change Standard Rapid-Change Standard Rapid-Change Standard Rapid-Change Standard Rapid-Change 129,85 305,00 265,00 265,00 249,00 141,95 311,00 278,00 278,00 260,00
