Driving motors and handpieces - joke Technology GmbH - #38

Text version of the page

43 1 nmax 8.000 1/min nmax 8.000 1/min nmax 8.000 1/min nmax 12.500 1/min 90 35 11 90 35 11 Ø 24 Ø 22,4 Ø 24 Ø 22,4 Ø 24 Ø 22,4 90 35 11 Ø 21,4 Ø 22,4 92 30 15 Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 1. Driving motors and handpieces // 1.2. Electric motor systems DIPROFIL® FMR/E 5 Mini hand-filing machines Order No. Price can be connected to micromotors J-BM 50 and J-BM 50 HT Stroke length 0.5 mm No. of strokes max. 8,000 strokes/min Tool receptacle Ø 3.5 mm Sound level < 70 dB(A) Vibration < 2.5 m/s2 Dimensions Ø 24 x 90 mm (without thread) Weight 120 g Accessories storage box, tools, oil, rubber covering (long) 0 001 207 DIPROFIL® FMR/E 10 Mini hand-filing machines Order No. Price can be connected to micromotors J-BM 50 and J-BM 50 HT Stroke length 1.0 mm No. of strokes max. 8,000 strokes/min Tool receptacle Ø 3.5 mm Sound level < 70 dB(A) Vibration < 2.5 m/s2 Dimensions Ø 24 x 90 mm (without thread) Weight 120 g Accessories storage box, tools, oil, rubber covering (long) 0 001 215 DIPROFIL® FMR/E 15 Mini hand-filing machines Order No. Price can be connected to micromotors J-BM 50 and J-BM 50 HT Stroke length 1.5 mm No. of strokes max. 8,000 strokes/min Tool receptacle Ø 3.5 mm Sound level < 70 dB(A) Vibration < 2.5 m/s2 Dimensions Ø 24 x 90 mm (without thread) Weight 120 g Accessories storage box, tools, oil, rubber covering (long) 0 001 209 Mini hand-filing machine N48 Order No. Price can be connected to ENESKA 4-1 micromotors J-BM 50 and J-BM 50 HT, with integrated step-down gear 4:1 Stroke length 0.8 mm No. of strokes max. 12,500 strokes/min, Motor speed max. 40,000 rpm Tool receptacle Ø 3.1 mm Dimensions Ø 22.4 x 92 mm (without thread) Weight 130g Accessories storage box, tools, oil 0 001 403 ENESKA 4-1 Mini hand-filing machines 482,00 482,00 482,00 535,00
