42 1 nmax 8.000 1/min nmax 8.000 1/min nmax 12.500 1/min nmax 50.000 1/min 15 60 12,5 6,5 Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 1. Driving motors and handpieces // 1.2. Electric motor systems suitable grinding belts can be found on page 26 Hand-filing machine DIPROFIL® FPT/ER Order No. Price can be connected to micromotors J-BM 50 and J-BM 50 HT Stroke length 0.5 - 6.0 mm, continuously adjustable No. of strokes max. 8,000 strokes/min Tool receptacle Ø 1.0 - 6.5 mm Insertion depth 32 mm Sound level < 70 dB(A) Vibration 7 - 8 m/s2 Weight 600 g Accessories storage box, tool set, maintenance set, rubber covering, oil 0 005 204 Hand-filing machine FMM/4 Order No. Price can be connected to ENESKA 4-1 Micromotors J-BM 50 and J-BM 50 HT, with step-down gear ratio 4:1 Stroke length 0 - 6 mm, continuously adjustable No. of strokes max. 12,500 strokes/min Tool support Ø 3.2 mm Weight 750 g Accessories storage box, tool holder, tool set, oil 0 005 300 ENESKA 4-1 Hand-filing machines • Belt grinder Hand-filing machine DIPROFIL® FPV/ER Order No. Price can be connected to micromotors J-BM 50 and J-BM 50 HT Stroke length 0.5 - 6.0 mm, continuously adjustable No. of strokes max. 8,000 strokes/min Tool receptacle Ø 1.0 - 3.5 mm, insertion depth 32 mm Sound level < 70 dB(A) Vibration 4 - 5 m/s2 Weight 600 g Accessories storage box, tool set, maintenance set, rubber covering, oil 0 005 208 Belt grinder J-BS 400 Order No. Price can be connected to ENESKA 4-1 micromotors J-BM 50 and J-BM 50 HT, for grinding belts 4, 6 and 8 mm wide Gearing 8:3 Input Speed max. 50,000 rpm Speed max. 18,000 rpm Weight 355 g Accessories two 6 x 300 mm grinding belts each, in grit sizes 120, 240 and 400 0 008 850 we recommend the reduction gear ERG-01 B (order no. 0 009 806) Belt Roll Arm 860,00 819,00 790,00 515,00
