41 1 nmax 20.000 1/min nmax 30.000 1/min nmax 50.000 1/min nmax 20.000 1/min 58 Ø 22,4 Ø 22,4 Ø 13,3 71 Ø 17,4 28,6 22 Ø 22,4 69,5 Ø 22,4 20 13 Ø 22,4 Ø 24 95 23 11 75 nmax 8.000 1/min 60 mm Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 1. Driving motors and handpieces // 1.2. Electric motor systems Transverse stroke max. 4 mm ENESKA 4-1 Handpieces for connection to micromotors of the systems ENESKA 4-1 and 4 Rapid-chuck handpiece JEHR-500 Order No. Price Collet CHH (Ø 3 mm when delivered) Speed max. 50,000 1/min, in continuous operation 40,000 rpm Concentricity ± 0.01 mm Dimensions Ø 22.4 x 58 mm (without thread) Weight 95 g 0 008 810 Handpiece J-EHG 400 Order No. Price Collet CHG (Ø 6 mm when delivered) Speed max. 30,000 1/min Concentricity ± 0.01 mm Dimensions Ø 22.4 x 75 mm (without thread) Weight 100 g 0 009 811 Angle handpiece J-ERA 270 Order No. Price Collet CHS (Ø 3 mm when delivered) Speed max. 20,000 1/min, reverse rotation Concentricity ± 0.01 mm Dimensions Ø 22.4 x 71 mm (without thread) Weight 100 g 0 009 812 Angle handpiece EKC 300 Order No. Price Collet CHC (Ø 3 mm when delivered) Speed max. 20,000 1/min, same rotation direction Concentricity ± 0.01 mm Dimensions Ø 22.5 x 69.5 mm (without thread) Weight 60 g 0 009 813 DIPROFIL® Transverse handpiece FMV/E Order No. Price Cross-stroke 0 - 4 mm, continuously adjustable No. of strokes max. 12,000 strokes/min Tool receptacle Ø 3.5 mm Sound level < 75 dB(A) Vibration < 2.5 m/s2 Dimensions Ø 25 x 95 mm (without thread) Weight 195 g 0 001 212 385,00 295,00 309,00 229,00 499,00
