39 1 74,7 Ø 22,4 Ø 27,4 Ø 27,4 107,7 87,7 Ø 22,4 121,5 Ø 22,4 40 Ø 22,4 29 Ø 19 Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 1. Driving motors and handpieces // 1.2. Electric motor systems ENESKA 4-1 Micromotors Micromotor J-BM 50 Order no. Price including cable 0 008 802 without cable 0 008 803 Brushless three-phase motor for operation of ENESKA 4-1 handpieces Output 140 W Torque 0.056 Nm Speed range 1,000 - 50,000 1/min Sound level < 58 dB(A) at 30,000 rpm Dimensions Ø 27.4 x 74.7 mm (without cable) Weight 117 g Micromotor J-BM 50 HT Order no. Price including cable 0 008 805 without cable 0 008 806 Brushless high-performance three-phase motor for operation of ENESKA 4-1 handpieces Output 200 W Torque 0.084 Nm Speed range 1,000 - 50,000 1/min Sound level < 62 dB(A) at 30,000 rpm Dimensions Ø 28.3 x 87.7 mm (without cable) Weight 160 g suitable cables Order no. Price Motor cable 1.5 m, straight 0 008 804 to connect micromotor J-BM 50 to ENESKA 4-1 control unit Motor cable 4.0 m, straight 0 008 808 suitable cables Order no. Price Motor cable 1.5 m, straight 0 008 807 to connect micromotor J-BM 50 HT to ENESKA 4-1 control unit Motor cable 4.0 m, straight 0 008 809 Step-down gear ERG-01 B Order no. Price For use with micromotors J-BM 50 and J-BM 50 HT Speed step-down ratio: 4 : 1. Speed: max. 30,000 1/min Dimension: Ø 22.4 x 40 mm (without thread) Weight: 65 g 0 009 806 Adapter ECN-01T Order no. Price To connect ENESKA 3-1 handpieces to micromotors J-BM 50 and J-BM 50 HT Speed: max. 30,000 1/min Dimension: Ø 22.4 x 29 mm (without thread) Weight: 65 g 0 009 807 638,00 549,00 668,00 562,00 117,25 190,00 117,25 190,00 120,20 57,30
