38 1 Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 1. Driving motors and handpieces // 1.2. Electric motor systems Control Unit J-ST 50 Order No. Price Continuous speed adjustment up to max. 50,000 1/min Output max. 200 W Speed restriction by potentiometer 2 motor connections Automatic motor recognition “Speed-Memory“ function Left / right operation Dimensions (W x H x D) 250 x 100 x 205 mm Weight 3.3 kg Power Supply 230 V, 50/60 Hz Accessories: 2 handpiece receptacles (Order No. 0 007 020) 0 008 801 ENESKA 4-1 set with standard motor Order No. Price The set contains: 1 x control unit J-ST50 (Order No. 0 008 801) 1 x brushless micromotor J-BM 50 complete with motor cable (Order No. 0 008 802) 1 x rapid-chuck handpiece JEHR-500 (Order No. 0 008 810) 1 x tray (Order No. 0 007 030) 2 x handpiece receptacles (Order No. 0 007 020) 0 008 800 ENESKA 4-1 set with high torque motor Order No. Price The set contains: 1 x control unit J-ST 50 (Order No. 0 008 801) 1 x brushless micromotor J-BM 50 HT complete with motor cable (Order No. 0 008 805) 1 x rapid-chuck handpiece JEHR-500 (Order No. 0 008 810) 1 x tray (Order No. 0 007 030) 2 x handpiece receptacles (Order No. 0 007 020) 0 008 820 Accessories for ENESKA 4-1 Order No. Price Handpiece tray 0 007 030 Foot control FC 40 0 009 804 ENESKA 4-1 Sets • Control unit • Accessories 1.680,00 1.730,00 857,00 20,45 78,85
