30 1 i 1 2 3 4 5 6 1. Driving motors and handpieces // 1.2. Electric motor systems Hand-filing machines with integrated micromotor Control unit DIPROFIL® DPU-3 Order no. 0 005 210 Hand-filing machines DIPROFIL® Classic DIPROFIL® FPP/ERJ Order no. 0 005 209 Tool receptacle: Ø 1 - 3.5 mm DIPROFIL® FPM/ERJ Order no. 0 005 202 Tool receptacle: Ø 1 - 6 mm DIPROFIL® FPM/ERVLJ Order no. 0 005 206 Tool receptacle: Ø 1 - 6.5 mm with extras long (120 mm) rotatable piston! Hand-filing machines DIPROFIL® Di-Pro DIPROFIL® Di-Pro FXP/EJ Order no. 0 001 502 Tool receptacle: Ø 1 - 3.5 mm DIPROFIL® Di-Pro FXM/EJ Order no. 0 001 521 Tool receptacle: Ø 1 - 6.5 mm Hand-filing machines JOKE® JOKE® FMD/3-1 Order no. 0 005 500 Tool receptacle: Ø 0.5 - 6 mm Need a direct connection? These hand-filing machines with an integrated motor can be directly connected to the control units of the ENESKA 3-1 series or to the control unit DIPROFIL® DPU-3 through an adapter (see below). Control unit DIPROFIL® DPU-3 Order no. Price for connection of hand-filing machines with integrated micromotor with foot control 0 005 210 variable no. of strokes adjustable Output voltage 0 - 32 V, DC at 1.2 A Dimensions (W x H x D) 115 x 147 x 96 mm Input voltage AC 110/230 V, 50/60 Hz Power consumption 100 W Weight control unit 1.7 kg foot control 0.6 kg Adapter cable for connection of hand-filing machines to the control unit DIPROFIL® DPU -3 Order no. Price 0 006 203-1 338,00 18,90
