26 1 15 12,5 60 6,5 nmax 40.000 1/min Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 1. Driving motors and handpieces // 1.2. Electric motor systems Belt grinder J-BS 100 Order No. Price For connection to micromotors JENK-410S and JENK-250T, fits 4, 6 and 8 mm wide grinding belts. delivered with two grinding belts 6 x 300 mm in grain sizes 120 - 240 - 400. Gearing 8:3 Input rotation Speed max. 40,000 rpm Output speed max. 15,000 rpm Weight 355 g 0 009 950 ENESKA 3-2 Belt grinder Belt grinder J-BS 100 Compliments the ENESKA 3-1 Mobile grinding, milling and polishing system. This belt grinder is screwed onto the micromotors, just like a handpiece. It is small and easy to handle, fits nicely in your hand and can be used on delicate jobs. The head can be swivelled on its axis by approximately 90°. A hand rest is located above the grinding belts to enable the device to be used safely with both hands. Grinding belts for J-BS 100 Dimensions Grit Packing unit Order No. Price Felt 8 x 300 - 5 belts 0 401 499 Corundum 6 x 300 120 10 belts 0 401 540 6 x 300 240 10 belts 0 401 541 6 x 300 320 10 belts 0 401 545 6 x 300 400 10 belts 0 401 542 6 x 300 500 10 belts 0 401 549 6 x 300 600 10 belts 0 401 547 8 x 300 # 80 50 belts 0 401 930 8 x 300 # 120 50 belts 0 401 931 8 x 300 # 180 50 belts 0 401 932 8 x 300 # 240 50 belts 0 401 933 8 x 300 # 320 50 belts 0 401 934 8 x 300 # 400 50 belts 0 401 935 8 x 300 # 600 50 belts 0 401 936 8 x 300 # 800 50 belts 0 401 937 8 x 300 # 1000 50 belts 0 401 938 Zirconium corundum 6 x 300 40 10 belts 0 401 546 6 x 300 60 10 belts 0 401 548 6 x 300 80 10 belts 0 401 543 6 x 300 120 10 belts 0 401 544 Belt Roll Arm 495,00 44,80 9,25 9,25 9,25 9,25 10,80 10,80 32,90 32,90 32,90 32,90 32,90 32,90 32,90 32,90 32,90 9,25 9,25 9,25 9,25
