24 1 D D D D nmax 10.000 1/min nmax 8.000 1/min nmax 8.000 1/min nmax 10.000 1/min Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 1. Driving motors and handpieces // 1.2. Electric motor systems Hand-filing machine DIPROFIL® FPT/NR Order No. Price For connection to micromotors JENK-410S and JENK-250T via reduction gear RG-01 (order no. 0 009 500) Stroke length 0.5 - 6 mm, continuously adjustable No. of strokes max. 8,000 strokes/min Tool receptacle Ø 1 – 6.5 mm insertion depth 32 mm Sound level < 70 dB(A) Vibration 7 - 8 m/s2 Weight 600 g Accessories storage box, tool set, maintenance set, rubber collar, oil 0 005 203 ENESKA 3-2 Hand-filing machines for connection to the system ENESKA 3-2 Hand-filing machine FMD/3-2 Order No. Price With built-in micromotor for direct connection to the ENESKA 3-2 control unit Stroke length 0.5 - 6 mm, continuously adjustable No. of strokes 1,000 - 10,000 strokes/min Tool receptacle Ø 1 – 6.2 mm Weight 800 g Accessories 2 tool holders, tool set, oil, storage box 0 005 550 Hand-filing machine FMM/3 Order No. Price For connection to micromotors JENK-410S and JENK-250T, with integrated step-down gear 4:1 Stroke length 0.5 – 6 mm, continuously adjustable No. of strokes max. 10,000 strokes/min with micromotor JNK-351 Tool receptacle Ø 1 – 6.2 mm Weight 750 g Accessories: 2 tool holders, tool set, oil, storage box 0 005 400 Hand-filing machine DIPROFIL® FPV/NR Order No. Price For connection to micromotors JENK-410S and JENK-250T via reduction gear RG-01 (order no. 0 009 500) Stroke length 0.5 - 6 mm, continuously adjustable No. of strokes max. 8,000 strokes/min Tool receptacle Ø 1 – 3.5 mm Insertion depth 32 mm Sound level < 70 dB(A) Vibration 4 - 5 m/s2 Weight 600 g Accessories storage box, tool set, maintenance set, rubber collar, oil 0 005 205 1.190,00 819,00 861,00 790,00
