23 1 Ø 18,1 P P Ø 19 Ø 25 102 62,5 nmax 27.000 1/min nmax 40.000 1/min Inno-Check ƒô ƒô ƒô ƒô Ø 19,3 Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 1. Driving motors and handpieces // 1.2. Electric motor systems ENESKA 3-2 Handpieces for connection to micromotors of the systems ENESKA 3-2, 3-1 and 3 Handpiece JHG 210 Order No. Price Collet CHG (Ø 6 mm in scope of delivery) Rotation speed max. 27,000 1/min Concentricity ± 0.01 mm Dimensions Ø 25 x 102 mm (without thread) Weight 180 g 0 007 650 NEW! NEW! NEW! Filigree-Handpiece JIG-400 Order No. Price Collet CHG (3 mm in scope of delivery) Rotation speed max. 40,000 1/min Concentricity ± 0.01 mm Dimensions Ø 19.3 x 62.5 mm (without thread) Weight 46 g 0 007 530 New collet technology with retainer nut Markedly greater clamping force (ideal for milling etc.) Small, filigree light weight (only 46 g!) Absolute true running! A top new arrival among our handpieces: Filigree handpiece JIG-400 markedly enlarged illustration (approx. 300%!) accessories Order No. Price Collet (Type NKM 6) Ø 2.35 mm 0 007 532 Collet (Type NKM 6) Ø 3.0 mm 0 007 533 Collet (Type NKM 6) 1/8“ / Ø 3.0 mm 0 007 534 Collet nut 0 007 531 246,00 287,00 59,20 59,20 59,20 36,55
