22 1 Ø 19 nmax 15.000 1/min nmax 15.000 1/min nmax 35.000 1/min nmax 20.000 1/min nmax 20.000 1/min nmax 40.000 1/min nmax 40.000 1/min Ø 19 60 Ø 14,5 22 62 Ø 19 20 Ø13 20 58 Ø 19 Ø13 128,5 67 Ø13 Ø 19 95 Ø 19 Ø9,8 Ø14 97 Ø 19 65 27 Ø 15 Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 1. Driving motors and handpieces // 1.2. Electric motor systems ENESKA 3-2 Handpieces for connection to micromotors of the systems ENESKA 3-2, 3-1 and 3 Handpiece JIH 300 Order no. Price Collet CHH (Ø 3 mm in scope od delivery) Rotation speed max. 40,000 1/min Concentricity ± 0.01 mm Dimensions Ø 23 x 60 mm (without thread) Weight 60 g 0 009 150 Angle handpiece JKC 345 Order No. Price Collet CHC (Ø 3 mm in scope od delivery) Speed max. 20,000 1/min, same rotation direction Concentricity ± 0.01 mm Dimensions Ø 22 x 62 mm (without thread) Weight 60 g 0 009 200 Angle handpiece JIC 390 Order No. Price Collet CHC (Ø 3 mm in scope od delivery) Speed max. 20,000 1/min, reverse rotation Concentricity ± 0.01 mm Dimensions Ø 22 x 58 mm (without thread) Weight 60 g 0 009 250 Handpiece JBMH 300 N Order No. Price Collet CHM (Ø 3 mm in scope od delivery) Speed max. 35,000 1/min Dimensions Ø 19 x 128.5 mm (without thread) Concentricity ± 0.01 mm Weight 160 g 0 009 350 Miniature angle handpiece JMFC-300 M Order No. Price Collet K-252 (Ø 1.6 mm in scope od delivery) Speed max. 15,000 1/min, reverse rotation Dimensions Ø 19 x 95 mm (without thread) Concentricity ± 0.01 mm Weight 47 g 0 009 511 Miniature angle handpiece JMFC-300 S Order No. Price Collet K-253 (Ø 1,6 mm in scope od delivery) Speed max. 15,000 1/min, reverse rotation Dimensions Ø 19 x 95 mm (without thread) Concentricity ± 0.01 mm Weight 50 g 0 009 512 Rapid-chuck handpiece JIR 310 Order no. Price Collet CHH (Ø 3 mm in scope od delivery) Rotation speed max. 40,000 1/min Concentricity ± 0.01 mm Dimensions Ø 24 x 75 mm (without thread) Weight 90 g 0 007 515 NEW! NEW! 251,00 247,00 196,00 196,00 271,00 198,00 222,00
