20 1 Ø 19 42 Ø 19 50 Ø 28,4 Ø 19 Ø 24,5 78,4 67,1 Ø 19 Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 1. Driving motors and handpieces // 1.2. Electric motor systems ENESKA 3-2 Micromotors and accessories Micromotor JENK-410S (Standard) Order no. Price Brushless alternating currrent motor Power max. 73 watts Rotation speed range 1,000 – 40,000 1/min Torque 4.2 N/cm² Dimensions Ø 24.5 x 67.1 mm Weight 90 g 0 007 505 suitable cable Order no. Price Motorcable JENK-250T, straight, 1.6 m 0 007 526 to connect the micromotor JENK-250T with the ENESKA 3-2 control unit NE 270, length: 1.6 m Motorcable JENK-250T, straight, 4 m 0 007 527 suitable cable Order no. Price Motorcable JENK-410S, straight, 1.6 m 0 007 506 to connect the micromotor JENK-410S with the ENESKA 3-2 control unit NE 270, length: 1.6 m Motorcable JENK-410S, straight, 4 m 0 007 507 Micromotor JENK-250T (High Torque) Order no. Price Brushless alternating currrent motor Power max. 76 watts Rotation speed range 1,000 – 25,000 1/min Torque 4.8 N/cm² Dimensions Ø 28.4 x 78.4 mm Weight 147 g 0 007 525 Step-down gear RG-01 Order no. Price for connection to the ENESKA 3-2 micromotors JENK-250T and JENK-410S. Reduces rotation speed 4:1 Rotation speed max. 30,000 1/min Dimensions Ø 19 x 55 mm Weight 68 g 0 009 500 Extension element CN-01 Order no. Price for connection to the ENESKA 3-2 micromotors JENK-250T and JENK-410S as well as step-down gear RG-01 Rotation speed max. 40,000 1/min Dimensions Ø 19 x 63.5 mm Weight 83 g 0 009 505 NEW! 467,00 418,00 159,00 246,00 159,00 246,00 118,70 73,60
