305 3 i i Bestseller! Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 3. Diamond and CBN tools // 3.1. Diamond and CBN grinding points Precision diamond grinding points These points are the perfect partner for our high-speed handpiece P 320 and the handpieces of the ENESKA systems 3-1 and 4-1. Areas of use Casting alloys Precious metal alloys Ceramic Plastics Precision diamond grinding points, galvanic bonding, shank Ø 1.6 mm Shape Head dimensions mm Shank Ø x total length Grit size Order No. Price Cylinder Ø 1.0 x 4.0 Ø 1.6 x 19 D 46 0 560 585 Ø 1.0 x 4.0 Ø 1.6 x 19 D 126 0 560 575 Ø 1.4 x 4.8 Ø 1.6 x 19 D 46 0 560 586-1 Ø 1.8 x 4.0 Ø 1.6 x 19 D 126 0 560 576 Round cylinder Ø 1.0 x 4.0 Ø 1.6 x 19 D 126 0 560 557 Ø 1.4 x 6.0 Ø 1.6 x 19 D 46 0 560 587-1 Ø 1.4 x 4.0 Ø 1.6 x 19 D 126 0 560 577 Sphere Ø 1.0 Ø 1.6 x 19 D 46 0 560 580 Ø 1.0 Ø 1.6 x 19 D 126 0 560 570 Ø 1.6 Ø 1.6 x 19 D 46 0 560 581 Ø 1.6 Ø 1.6 x 19 D 126 0 560 571 Ø 1.8 Ø 1.6 x 19 D 46 0 560 590 Ø 2.1 Ø 1.6 x 19 D 46 0 560 582 Ø 2.1 Ø 1.6 x 19 D 126 0 560 572 Wheel Ø 1.8 x 0.7 Ø 1.6 x 19 D 126 0 560 573 Ø 4.70 x 0.50 Ø 1.6 x 19 D 126 0 560 593 Round nose Ø 1.2 x 10.0 Ø 1.6 x 19 D 46 0 560 588 Ø 1.2 x 10.0 Ø 1.6 x 19 D 126 0 560 578 Ø 1.6 x 10.0 Ø 1.6 x 19 D 46 0 560 589 Ø 1.4 x 11.5 Ø 1.6 x 19 D 46 0 560 594 Ø 1.6 x 10.0 Ø 1.6 x 19 D 126 0 560 579 Pointed cone Ø 1.2 x 8.0 Ø 1.6 x 19 D 46 0 560 595 Pear-shape Ø 1.0 x 2.0 Ø 1.6 x 19 D 46 0 560 584 Ø 1.0 x 2.0 Ø 1.6 x 19 D 126 0 560 574 Precision diamond grinding points shank Ø 1.6 mm Sets Order No. Set price Set of diamond grinding points, D 46 0 560 505-1 Contents: 12 units Set of diamond grinding points, D 126 0 560 504 Contents: 12 units All measurements in mm Minimum order amount: 5 pieces Recommendations for the use of these precision grinding points: • Always observe recommended rotation speed • Avoid excess grinding pressure • Bring grinding tools to working speed before use • Do not use damaged and/or blunt tools • Avoid getting jammed and leveraging Working Ø of the tool 0.7 - 1.0 mm 1.2 - 1.4 mm 1.6 - 1.8 mm 2.1 - 2.3 mm 2.5 - 2.7 mm 2.9 - 3.1 mm 3.3 - 4.0 mm 4.2 - 5.0 mm 5.5 - 7.0 mm 8.0 - 10.0 mm Max. perm. rpm 450,000 rpm 450,000 rpm 450,000 rpm 300,000 rpm 160,000 rpm 140,000 rpm 120,000 rpm 95,000 rpm 60,000 rpm 45,000 rpm Recommended rpm 100,000 - 200,000 rpm 70,000 - 220,000 rpm 55,000 - 160,000 rpm 40,000 - 120,000 rpm 35,000 - 110,000 rpm 30,000 - 95,000 rpm 25,000 - 75,000 rpm 15,000 - 60,000 rpm 12,000 - 40,000 rpm 10,000 - 20,000 rpm
