3 305 306 310 320 325 326 330 331 334 336 337 338 344 347 Diamond and CBN grinding points Diamond grinding points shank Ø 1.6 mm Diamond grinding points shank Ø 2.35 mm Diamond grinding points shank Ø 3 mm Diamond grinding points shank Ø 6 mm Diamond grinding points vacuum brazed bonding CBN grinding points shank Ø 3 mm CBN grinding points shank Ø 6 mm Diamond hollow drill Diamond deburring tools Diamond spring steel wires Diamond hand lappers Diamond grinding wheels and discs Diamond dressers Diamond abrasive sheets and films Diamond and CBN grinding points are available in four different bonding types. The standard is galvanic bonding, in which a layer of abrasive is “applied” to the base body. In addition, we offer tools with a metal or resin bonding, in which the diamond grits are completely embedded in the bonding. Finally, vacuum brazed bonding, in which the grit is directly welded to the base material – for even better service lives and maximum cutting efficiency. Galvanic bonding Abrasive is “applied” in a layer of nickel Metal/resin bonding The diamonds are completely embedded in the bonding Vacuum brazed bonding The grit is directly welded to the base material
