346 3 i 0 100 200 300 400 0 Scheibendurchmesser in mm Scheibenbreite in mm 100 200 300 400 2,75 ct 1 ct 1,5 ct 1,75 ct Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 3. Diamond and boron nitride tools // 3.4. Diamond dressers Diamond multi-grit dressers Diamond multi-grit dressers Multi grain dressers can be used until they are worn out. The diamond disc is completely interspersed with diamond grit. Due to the low planing forces, these dressers are predominantly used for narrow, sharp-edged and pointed wheels. Choice of multi grain dressers in relation to the grinding wheel size. Diamond multi-grit dressers Total length; mm Grit size of grinding wheel to be dressed Diamond weight; carat Grit size Order No. Price from 5 pieces Price from 1 piece MK 0 40 180-400 1 ct D 213 0 562 305 40 46-120 1 ct D 851 0 562 301 MK 1 60 180-400 1.75 ct D 213 0 562 315 60 46-120 1.75 ct D 851 0 562 311 60 46-120 2.75 ct D 851 0 562 312 Ø 8 x 100 100 180-400 1 ct D 213 0 562 365 100 46-120 1 ct D 851 0 562 361 100 46-120 1.4 ct D 851 0 562 362 Ø 12 x 150 150 180-400 2.75 ct D 213 0 562 386 150 46-120 2.75 ct D 851 0 562 382 Diamond multi-grit hand dressers Order No. Price from 5 pieces Price from 1 piece Total length 120 mm, for dressing grinding points up to Ø 25 mm, usable diamond Ø 5 x 5 mm. 0 540 990 Wheel width in mm Wheel diameter in mm
