345
3
i
0
100
200
300
400
500
0 200 400 600
Scheibendurchmesser in mm
Scheibenbreite in mm
3 Steine
1,0 ct
6 Steine
1,0 ct
Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de
3. Diamond and boron nitride tools // 3.4. Diamond dressers
Diamond multiple-stone dressers Total
length; mm
Diamond distribution Diamond
weight; carat
Order No. Price from
5 pieces
Price from
1 piece
MK 0 31.5 1 Layer - 3 Stones 1.0 ct 0 562 270
31.5 1 Layer - 6 Stones 1.0 ct 0 562 273
MK 1 51 1 Layer - 3 Stones 1.0 ct 0 562 271
51 1 Layer - 6 Stones 1.0 ct 0 562 274
Ř 8 x 90 90 1 Layer - 3 Stones 1.0 ct 0 562 272
90 1 Layer - 6 Stones 1.0 ct 0 562 275
Diamond multiple-stone dressers
Diamond multiple-stone dressers
Multi stone dressers are normally used for
large, very wide grinding wheels. Since a large
diamond surface is used in the multiple-stone
dresser, the load is optimally distributed.
Choice of a multiple-stone dresser in relation
to the grinding wheel size.
Wheel width in mm
Wheel diameter in mm
6 stones
3 stones
