344 3 0 20 40 60 80 100 120 140 160 180 200 220 240 0 200 400 600 Scheibendurchmesser in mm Scheibenbreite in mm 0,3 ct 0,5 ct 0,75 ct 1,0 ct i Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 3. Diamond and boron nitride tools // 3.4. Diamond dressers Diamond single-stone dressers Total length; mm Diamond weight; carat Order No. Price from 5 pieces Price from 1 piece MK 0 31.5 0.3 ct 0 562 004 31.5 0.5 ct 0 562 010 31.5 0.75 ct 0 562 017 31.5 1.0 ct 0 562 018 MK 1 49 0.3 ct 0 562 034 49 0.5 ct 0 562 040 49 0.75 ct 0 562 047 49 1.0 ct 0 562 048 Ø 6 30 0.3 ct 0 562 064 30 0.5 ct 0 562 070 Ø 6 / Ø 10 25 0.3 ct 0 562 094 25 0.5 ct 0 562 100 25 0.75 ct 0 562 107 Ø 8 30 0.3 ct 0 562 124 30 0.5 ct 0 562 130 90 0.3 ct 0 562 184 90 0.5 ct 0 562 190 90 1.0 ct 0 562 194 Ø 10 60 0.3 ct 0 562 154 60 0.5 ct 0 562 160 60 0.75 ct 0 562 167 Diamond single-stone dressers Diamond single-stone dressers The single diamonds have at least three working points (quality 03). They have a blockshaped, firmly textured crystal shape with inclusions. Please note: • Dressing sideways feed 0.05-0.2 mm/revolution • Adequate continuous cooling • Always protect the diamond against blows and impacts • Max. feed motion 0.03 mm • Place something under the centre of the disc at an angle of inclination of 5 - 15° Choice of single-stone dresser in relation to the grinding wheel size Wheel width in mm Wheel diameter in mm
