343 3 Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 3. Diamond and boron nitride tools // 3.3. Diamond abrasive discs and sheets Diamond abrasive strips JOKE® Dia-Speed Dimensions Bonding Grit size Colour Order No. Price Ø 15 x 30 mm Metal D 250 green 0 403 441 Metal D 126 black 0 403 442 Metal D 76 red 0 403 443 Metal D 46 yellow 0 403 444 Metal D 20 white 0 403 445 Resin D 15 yellow 0 403 446 Resin D 7 blue 0 403 447 Resin D 3 orange 0 403 448 Ø 22 x20 mm Metal D 250 green 0 403 451 Metal D 126 black 0 403 452 Metal D 76 red 0 403 453 Metal D 46 yellow 0 403 454 Metal D 20 white 0 403 455 Resin D 15 yellow 0 403 456 Resin D 7 blue 0 403 457 Resin D 3 orange 0 403 458 suitable abrasive strip holder Shank dimensions mm Order No. Price from 10 pieces Price from 1 piece Abrasive strip holder, Ø 15 x 30 mm Ø 6 x 40 0 544 606 Abrasive strip holder, Ø 22 x 20 mm Ø 6 x 40 0 544 607 Featuring the same characteristics and benefits as the abrasive sheets Dia-Speed, but in sleeve form. Use in combination with the relevant rubber holder. Thanks to centrifugal force pressure, the sleeves remain securely on the holder even at high rotational speeds. Diamond abrasive strips JOKE® Dia-Speed Plastic/diamond cut-off discs JOKE® Dia-Disc Dimensions mm Bore Ø Grit size Colour Order No. Price from 5 pieces Price from 1 piece Ø 22 x 0.25 1.8 30 ì green 0 571 098 Ø 22 x 0.25 1.8 9 ì blue 0 571 099 Thin, highly flexible plastic discs filled with natural diamonds. The discs can be used on both sides for polishing zirconium, glass, titanium, stone and all steels. Ideal for narrow slots. Can be used with fluid or diamond paste. Max. speed: 5,000 rpm Plastic/diamond cut-off discs JOKE® Dia Disc grinding wheel holders Shank dimensions Bore Ø Max. disc size Order No. Price from 10 pieces Price from 1 piece Ø 2.35 Ø 1.5 - 1.8 Ø 37.5 x 4.5 0 545 275 Ø 3.0 Ø 1.5 - 1.8 Ø 37.5 x 4.5 0 545 276 Ø 3.0 Ø 1.5 - 1.8 Ø 38 x 3 0 545 278
