342
3
Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de
3. Diamond and boron nitride tools // 3.3. Diamond abrasive discs and sheets
Diamond abrasive discs
JOKE® Dia-Speed
Diamond abrasive discs JOKE® Dia-Speed Dimensions Bonding Grit size Colour Order No. Price
Ø 25 mm Metal D 250 green 0 403 421-1
Metal D 126 black 0 403 422-1
Metal D 76 red 0 403 423-1
Metal D 46 yellow 0 403 424-1
Metal D 20 white 0 403 425-1
Resin D 15 yellow 0 403 426-1
Resin D 7 blue 0 403 427-1
Resin D 3 orange 0 403 428-1
Ø 50 mm Metal D 250 green 0 403 431-1
Metal D 126 black 0 403 432-1
Metal D 76 red 0 403 433-1
Metal D 46 yellow 0 403 434-1
Metal D 20 white 0 403 435-1
Resin D 15 yellow 0 403 436-1
Resin D 7 blue 0 403 437-1
Resin D 3 orange 0 403 438-1
matching mandrels Shank dimensions Order No. Price
Mandrel for disc Ø 25 mm Ø 6 x 30 mm 0 403 429-1
Mandrel for disc Ø 50 mm Ø 6 x 30 mm 0 403 439-1
Highly flexible, diamond-coated abrasive
discs. Only to be used wet in order to avoid
overheating and and separation of the
diamond coating. Furthermore, coolants
improve chip clearance and and result in
better surface finishing with less wear.
Thanks to the high abrasive force of the
diamonds, Dia-Speed abrasive discs
do not require any high contact pressure.
Areas of use: Tungsten carbide,
ceramic, glass, hardened steels, stone.
