341 3 H D E T Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 3. Diamond and boron nitride tools // 3.3. Diamond abrasive discs and sheets Diamond cut-off discs with closed rim Diamond cut-off discs, galvanic bonding Dimensions D x T Bore Ø Blade thickness Grit size matching receptacle Order No. Price from 5 pieces Price from 1 piece Ø 20.0 x 0.85 5.0 0.5 D 126 TA5 0 561 641 Ø 20.0 x 0.95 5.0 0.5 D 181 TA5 0 561 642 Ø 20.0 x 1.35 5.0 1.0 D 126 TA5 0 561 643 Ø 20.0 x 1.45 5.0 1.0 D 181 TA5 0 561 644 Ø 25.0 x 0.85 8.0 0.5 D 126 TA8 0 561 645 Ø 25.0 x 0.95 8.0 0.5 D 181 TA8 0 561 646 Ø 25.0 x 1.35 8.0 1.0 D 126 TA8 0 561 647 Ø 25.0 x 1.45 8.0 1.0 D 181 TA8 0 561 648 Ø 30.0 x 0.7 6.0 0.3 D 126 TA6 0 561 651 Ø 30.0 x 0.8 6.0 0.3 D 181 TA6 0 561 650 Ø 30.0 x 0.9 6.0 0.5 D 126 TA6 0 561 653 Ø 30.0 x 1.0 6.0 0.5 D 181 TA6 0 561 652 Ø 30.0 x 1.4 6.0 1.0 D 126 TA6 0 561 655 Ø 30.0 x 1.5 6.0 1.0 D 181 TA6 0 561 654 Ø 40.0 x 0.85 10.0 0.5 D 126 TA10 0 561 656 Ø 40.0 x 0.95 10.0 0.5 D 181 TA10 0 561 657 Ø 40.0 x 1.35 10.0 1.0 D 126 TA10 0 561 658 Ø 40.0 x 1.45 10.0 1.0 D 181 TA10 0 561 659 Ø 50.0 x 0.85 13.0 0.5 D 126 TA13 0 561 661 Ø 50.0 x 0.95 13.0 0.5 D 181 TA13 0 561 664 Ø 50.0 x 1.35 13.0 1.0 D 126 TA13 0 561 665 Ø 50.0 x 1.45 13.0 1.0 D 181 TA13 0 561 662 Ø 65.0 x 0.9 8.0 0.5 D 126 TA8-G 0 561 670 Ø 65.0 x 1.0 8.0 0.5 D 181 TA8-G 0 561 669 Ø 75.0 x 0.9 22.0 0.5 D 126 - 0 561 679 Ø 75.0 x 1.0 22.0 0.5 D 181 - 0 561 678 Ø 100.0 x 0.9 22.0 0.5 D 126 - 0 561 691 Ø 100.0 x 1.0 22.0 0.5 D 181 - 0 561 690 Ø 100.0 x 1.4 22.0 1.0 D 126 - 0 561 694 Ø 100.0 x 1.5 22.0 1.0 D 181 - 0 561 693 Ø 125.0 x 1.4 22.0 1.0 D 126 - 0 561 703 Ø 125.0 x 1.5 22.0 1.0 D 181 - 0 561 702 Ø 150.0 x 1.4 22.0 1.0 D 126 - 0 561 712 all measurements in mm
