335 3 25 Ød ØD 25 Ød ØD Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 3. Diamond and CBN tools // 3.2. Diamond and CBN deburring tools Diamond bullets, slotted Design Nominal size D Shank dimensions Total length Grit size Order No. Price with adjustable recess Ø 2.5 Ø 6 x 25 60 D 76 0 562 570 Ø 3.0 Ø 6 x 25 60 D 76 0 562 571 Ø 3.5 Ø 6 x 25 60 D 76 0 562 572 Ø 4.0 Ø 6 x 25 60 D 76 0 562 573 Ø 4.5 Ø 6 x 25 60 D 76 0 562 574 Ø 5.0 Ø 6 x 25 80 D 76 0 562 575 Ø 5.5 Ø 6 x 25 80 D 76 0 562 576 Ø 6.0 Ø 6 x 25 80 D 76 0 562 577 Ø 6.5 Ø 8 x 25 80 D 76 0 562 578 Ø 7.0 Ø 8 x 25 80 D 76 0 562 579 Ø 7.5 Ø 8 x 25 80 D 76 0 562 580 Ø 8.0 Ø 8 x 25 80 D 76 0 562 581 Ø 8.5 Ø 10 x 25 100 D 76 0 562 582 Ø 9.0 Ø 10 x 25 100 D 76 0 562 583 Ø 9.5 Ø 10 x 25 100 D 76 0 562 584 Ø 10.0 Ø 10 x 25 100 D 76 0 562 585 without adjustable recess Ø 1.5 Ø 4 x 25 60 D 76 0 562 550 Ø 2.0 Ø 4 x 25 60 D 76 0 562 551 Ø 2.5 Ø 4 x 25 60 D 76 0 562 552 Ø 3.0 Ø 4 x 25 60 D 76 0 562 553 Ø 3.5 Ø 4 x 25 60 D 76 0 562 554 Ø 4.0 Ø 4 x 25 60 D 76 0 562 555 Ø 4.5 Ø 6 x 25 80 D 76 0 562 556 Ø 5.0 Ø 6 x 25 80 D 76 0 562 557 Ø 5.5 Ø 6 x 25 80 D 76 0 562 558 Ø 6.0 Ø 6 x 25 80 D 76 0 562 559 Ø 6.5 Ø 8 x 25 80 D 76 0 562 560 Ø 7.0 Ø 8 x 25 80 D 76 0 562 561 Ø 7.5 Ø 8 x 25 80 D 76 0 562 562 Ø 8.0 Ø 8 x 25 80 D 76 0 562 563 Ø 8.5 Ø 10 x 25 100 D 76 0 562 564 Ø 9.0 Ø 10 x 25 100 D 76 0 562 565 Ø 9.5 Ø 10 x 25 100 D 76 0 562 566 Ø 10.0 Ø 10 x 25 100 D 76 0 562 567 Diamond/CBN bullets, slotted with and without adjustable elastic recess Diamond bullets, slotted Simple tools which come into their own when deburring hard materials. They can be used in vertical drills, for manual operation or in machining centres (serial production). Available with or without elastic recess. Typical deburring applications: • Interconnected bore holes with various diameters in the hydraulics industry and in general mechanical engineering • Guide bore holes in valve block manufacturing • Components for the automotive industry (i.e. leak oil or throttle bore holes) • Small bore holes for vendor parts (i.e. oil, lube or relief bore holes) • Turning parts with cross-holes all measurements in mm Processing range: nominal dimensions Ø : Processing range: nominal dimensions Ø : + 0.2 mm - 0.1 mm + 0.2 mm - 0.1 mm
