Text version of the page
334
3
25
ØD
Ød
i
Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de
3. Diamond and CBN tools // 3.2. Diamond and CBN deburring tools
Diamond/CBN reamers
with adjustable recess
Diamond/CBN reamers Design Nominal size
D x coating length
Shank
dimensions
Total
length
Grit
size
Order No. Price
Diamond Ø 2 x 10 Ø 6 x 25 80 D 76 0 561 240
Ø 3 x 20 Ø 6 x 25 80 D 91 0 561 241
Ø 4 x 20 Ø 6 x 25 80 D 126 0 561 242
Ø 5 x 30 Ø 5 x 25 100 D 126 0 561 243
Ø 6 x 30 Ø 6 x 25 100 D 126 0 561 244
Ø 8 x 40 Ø 8 x 25 140 D 126 0 561 245
Ø 10 x 40 Ø 10 x 25 140 D 126 0 561 246
Ø 12 x 40 Ø 12 x 25 140 D 126 0 561 247
CBN Ø 2 x 10 Ø 6 x 25 80 B 76 0 566 240
Ø 3 x 20 Ø 6 x 25 80 B 91 0 566 241
Ø 4 x 20 Ø 6 x 25 80 B 126 0 566 242
Ø 5 x 30 Ø 5 x 25 100 B 126 0 566 243
Ø 6 x 30 Ø 6 x 25 100 B 126 0 566 244
Ø 8 x 40 Ø 8 x 25 140 B 126 0 566 245
Ø 10 x 40 Ø 10 x 25 140 B 126 0 566 246
Ø 12 x 40 Ø 12 x 25 140 B 126 0 566 247
Diamond/CBN reamers
These tools convince with their robust and
user-friendly construction and extraordinary
durability. As the advancement of conventional
lapping arbors, these reamers can be used
without paste – so that no time-consuming
cleaning is necessary. Design features fixed
shank, cylindrical clamping; slotted front and
continuously adjustable with locking screw.
Main applications:
• Finishing-machining of hardened pressdrilling
for tool and mould making
• Reworking on hard ejector drilling and
sleeves for the plastics industry
• Fine machining and finishing for largescale
production on transfer lines and
machining centres
all measurements in mm
Diamond or boron nitride?
That depends on the hardness of the
material:
• Diamond for tungsten carbide,, ceramics
and steel up to 57 HRC
• Boron nitride for hardened steel up
to 58 HRC
maximum processing range:
nominal dimensions Ø D
optimum processing range:
nominal dimensions Ø D
+ 0.2 mm
- 0.05 mm
± 0.03 mm
Recommended cutting speed: V = 12 – 15 m/min.
Special dimensions available on request!
