Diamond and boron nitride tools - joke Technology GmbH - #34

Text version of the page

331 3 T D 3,0 3,0 6,0 Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 3. Diamond and CBN tools // 3.1. Diamond and CBN grinding points CBN grinding points, solid tungsten carbide, galvanic bonding, shank Ø 6 mm Head dimensions D x T Neck dimensions d x L1 Shank Ø x total length Grit size Order No. Price from 5 pieces Price from 1 piece Ø 12 x 10 - Ø 6 x 60 B 126 0 565 837 Ø 12 x 10 - Ø 6 x 60 B 181 0 565 836 Ø 15 x 6 - Ø 6 x 60 B 91 0 565 381 Ø 15 x 6 - Ø 6 x 60 B 126 0 565 380 Ø 15 x 6 - Ø 6 x 60 B 181 0 565 379 Ø 15 x 10 - Ø 6 x 60 B 126 0 565 846 Ø 15 x 10 - Ø 6 x 60 B 181 0 565 845 CBN grinding points shank Ø 6 mm Vrecom. wet = 30 m/s • Vrecom. dry = 20 m/s max. • max. extension length = 0.5 x L Diamond hollow drill, electroplated Head dimensions Shank Dimensions Drilling depth Flush drilling Grit size Order No. Price from 10 pieces Price from 1 piece Ø 2 x 7 Ø 3 x 38 7 Ø 1 x 4 D 107 0 560 040 Ø 3 x 10 Ø 3 x 35 7 Ø 1.5 x 4 D 151 0 560 041 Ø 4 x 10 Ø 3 x 35 7 Ø 2 x 4 D 151 0 560 042 Ø 5 x 10 Ø 3 x 38 7 Ø 2 x 4 D 151 0 560 043 Ø 6 x 10 Ø 3 x 35 7 Ø 2 x 4 D 151 0 560 044 Ø 8 x 10 Ø 3 x 35 7 Ø 3 x 4 D 151 0 560 045 Diamond hollow drill shank Ø 3 mm Electroplated hollow drills for drilling in thin ceramic, glass, carbide green body and other slabs. Examples of use: Blank drilling All measurements in mm All measurements in mm
