330 3 D T L1 d T D 3,0 6,0 Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 3. Diamond and CBN tools // 3.1. Diamond and CBN grinding points CBN grinding points shank Ø 6 mm Vrecom. wet = 30 m/s • Vrecom. dry = 20 m/s max. • max. extension length = 0.5 x L CBN grinding points, solid tungsten carbide, galvanic bonding, shank Ø 6 mm Head dimensions D x T Neck dimensions d x L1 Shank Ø x total length Grit size Order No. Price from 5 pieces Price from 1 piece Cylinder Ø 2 x 4 Ø 1.7 x 20 Ø 6 x 60 B 91 0 565 382 Ø 2 x 4 Ø 1.7 x 20 Ø 6 x 60 B 126 0 565 383 Ø 2 x 4 Ø 1.7 x 20 Ø 6 x 60 B 181 0 565 384 Ø 3 x 5 Ø 2.7 x 20 Ø 6 x 60 B 91 0 565 385 Ø 3 x 5 Ø 2.7 x 20 Ø 6 x 60 B 126 0 565 386 Ø 3 x 5 Ø 2.7 x 20 Ø 6 x 60 B 181 0 565 387 Ø 4 x 7 Ø 3.7 x 20 Ø 6 x 60 B 91 0 565 388 Ø 4 x 7 Ø 3.7 x 20 Ø 6 x 60 B 126 0 565 389 Ø 4 x 7 Ø 3.7 x 20 Ø 6 x 60 B 181 0 565 390 Ø 5 x 7 Ø 4.7 x 20 Ø 6 x 60 B 91 0 565 391 Ø 5 x 7 Ø 4.7 x 20 Ø 6 x 60 B 126 0 565 392 Ø 5 x 7 Ø 4.7 x 20 Ø 6 x 60 B 181 0 565 393 Ø 6 x 7 Ø 5.7 x 20 Ø 6 x 60 B 91 0 565 358 Ø 6 x 7 Ø 5.7 x 20 Ø 6 x 60 B 126 0 565 357 Ø 6 x 7 Ø 5.7 x 20 Ø 6 x 60 B 181 0 565 356 Ø 6 x 20 - Ø 6 x 60 B 126 0 565 819 Ø 6 x 20 - Ø 6 x 60 B 181 0 565 818 Ø 8 x 6 - Ø 6 x 60 B 126 0 565 822 Ø 8 x 6 - Ø 6 x 60 B 181 0 565 821 Ø 10 x 6 - Ø 6 x 60 B 91 0 565 366 Ø 10 x 6 - Ø 6 x 60 B 126 0 565 365 Ø 10 x 6 - Ø 6 x 60 B 181 0 565 364 Ø 10 x 10 - Ø 6 x 60 B 126 0 565 828 Ø 10 x 10 - Ø 6 x 60 B 181 0 565 827 Ø 10 x 15 - Ø 6 x 60 B 126 0 565 831 Ø 10 x 15 - Ø 6 x 60 B 181 0 565 830 Ø 12 x 6 - Ø 6 x 60 B 91 0 565 371 Ø 12 x 6 - Ø 6 x 60 B 126 0 565 370 Ø 12 x 6 - Ø 6 x 60 B 181 0 565 369 All measurements in mm
