329 3 D T L1 d 3,0 Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 3. Diamond and CBN tools // 3.1. Diamond and CBN grinding points CBN grinding points, solid tungsten carbide, galvanic bonding, shank Ø 3 mm Head dimensions D x T Neck dimensions d Shank Ø x total length Grit size Order No. Price from 5 pieces Price from 1 piece Ø 1.8 x 4 Ø 1.6 x 15 Ø 3 x 40 B 76 0 565 085 Ø 1.5 x 15 Ø 3 x 40 B 107 0 565 086 Ø 1.5 x 15 Ø 3 x 40 B 151 0 565 087 Ø 1.9 x 4 Ø 1.7 x 15 Ø 3 x 40 B 76 0 565 088 Ø 1.6 x 15 Ø 3 x 40 B 107 0 565 089 Ø 1.6 x 15 Ø 3 x 40 B 151 0 565 090 Ø 2.0 x 5 Ø 1.8 x 15 Ø 3 x 40 B 76 0 565 091 Ø 1.7 x 15 Ø 3 x 40 B 107 0 565 092 Ø 1.7 x 15 Ø 3 x 40 B 151 0 565 093 Ø 2.1 x 5 Ø 1.9 x 15 Ø 3 x 40 B 76 0 565 094 Ø 1.8 x 15 Ø 3 x 40 B 107 0 565 095 Ø 1.8 x 15 Ø 3 x 40 B 151 0 565 096 Ø 2.2 x 5 Ø 2.0 x 15 Ø 3 x 40 B 76 0 565 097 Ø 1.9 x 16 Ø 3 x 40 B 107 0 565 098 Ø 1.9 x 16 Ø 3 x 40 B 151 0 565 099 Ø 2.3 x 5 Ø 2.1 x 16 Ø 3 x 40 B 76 0 565 100 Ø 2.0 x 16 Ø 3 x 40 B 107 0 565 101 Ø 2.0 x 15 Ø 3 x 40 B 151 0 565 102 Ø 2.4 x 5 Ø 2.2 x 16 Ø 3 x 40 B 76 0 565 103 Ø 2.1 x 16 Ø 3 x 40 B 107 0 565 104 Ø 2.1 x 16 Ø 3 x 40 B 151 0 565 105 Ø 2.5 x 5 Ø 2.3 x 16 Ø 3 x 40 B 76 0 565 106 Ø 2.2 x 16 Ø 3 x 40 B 107 0 565 107 Ø 2.2 x 16 Ø 3 x 40 B 151 0 565 108 Ø 2.6 x 5 Ø 2.4 x 16 Ø 3 x 40 B 76 0 565 109 Ø 2.3 x 16 Ø 3 x 40 B 107 0 565 110 Ø 2.3 x 16 Ø 3 x 40 B 151 0 565 111 Ø 2.7 x 5 Ø 2.5 x 17 Ø 3 x 40 B 76 0 565 112 Ø 2.4 x 16 Ø 3 x 40 B 107 0 565 113 Ø 2.4 x 16 Ø 3 x 40 B 151 0 565 114 Ø 2.8 x 5 Ø 2.6 x 17 Ø 3 x 40 B 76 0 565 115 Ø 2.5 x 17 Ø 3 x 40 B 107 0 565 116 Ø 2.5 x 15 Ø 3 x 40 B 151 0 565 117 Ø 2.9 x 5 Ø 2.7 x 17 Ø 3 x 40 B 76 0 565 118 Ø 2.6 x 17 Ø 3 x 40 B 107 0 565 119 Ø 2.6 x 17 Ø 3 x 40 B 151 0 565 120 Ø 3.0 x 5 Ø 2.8 x 17 Ø 3 x 40 B 76 0 565 121 Ø 2.7 x 17 Ø 3 x 40 B 107 0 565 122 Ø 2.7 x 17 Ø 3 x 40 B 151 0 565 123 CBN grinding points, solid tungsten carbide shank Ø 3 mm All measurements in mm
