328 3 D T L1 d i 3,0 Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 3. Diamond and CBN tools // 3.1. Diamond and CBN grinding points CBN grinding points, solid tungsten carbide shank Ø 3 mm CBN grinding points, solid tungsten carbide, galvanic bonding, shank Ø 3 mm Head dimensions D x T Neck dimensions d Shank Ø x total length Grit size Order No. Price from 5 pieces Price from 1 piece Cylinder Ø 0.4 x 2 Ø 0.3 x 3 Ø 3 x 40 B 54 0 565 051 Ø 0.5 x 2 Ø 0.4 x 5 Ø 3 x 40 B 64 0 565 052 Ø 0.6 x 3 Ø 0.5 x 5 Ø 3 x 40 B 64 0 565 053 Ø 0.4 x 5 Ø 3 x 40 B 91 0 565 054 Ø 0.7 x 3 Ø 0.6 x 5 Ø 3 x 40 B 64 0 565 055 Ø 0.5 x 5 Ø 3 x 40 B 91 0 565 056 Ø 0.8 x 3 Ø 0.7 x 6 Ø 3 x 40 B 64 0 565 057 Ø 0.6 x 6 Ø 3 x 40 B 91 0 565 058 Ø 0.9 x 3 Ø 0.8 x 10 Ø 3 x 40 B 64 0 565 059 Ø 0.7 x 10 Ø 3 x 40 B 91 0 565 060 Ø 1.0 x 3 Ø 0.8 x 10 Ø 3 x 40 B 76 0 565 061 Ø 0.7 x 10 Ø 3 x 40 B 107 0 565 062 Ø 0.7 x 6 Ø 3 x 40 B 151 0 565 063 Ø 1.1 x 3 Ø 0.9 x 10 Ø 3 x 40 B 76 0 565 064 Ø 0.8 x 10 Ø 3 x 40 B 107 0 565 065 Ø 0.8 x 10 Ø 3 x 40 B 151 0 565 066 Ø 1.2 x 3 Ø 1.0 x 15 Ø 3 x 40 B 76 0 565 067 Ø 0.9 x 10 Ø 3 x 40 B 107 0 565 068 Ø 0.9 x 10 Ø 3 x 40 B 151 0 565 069 Ø 1.3 x 3 Ø 1.1 x 15 Ø 3 x 40 B 76 0 565 070 Ø 1.0 x 15 Ø 3 x 40 B 107 0 565 071 Ø 1.0 x 10 Ø 3 x 40 B 151 0 565 072 Ø 1.4 x 3 Ø 1.2 x 15 Ø 3 x 40 B 76 0 565 073 Ø 1.1 x 15 Ø 3 x 40 B 107 0 565 074 Ø 1.1 x 15 Ø 3 x 40 B 151 0 565 075 Ø 1.5 x 3 Ø 1.3 x 15 Ø 3 x 40 B 76 0 565 076 Ø 1.2 x 15 Ø 3 x 40 B 107 0 565 077 Ø 1.2 x 15 Ø 3 x 40 B 151 0 565 078 Ø 1.6 x 4 Ø 1.4 x 15 Ø 3 x 40 B 76 0 565 079 Ø 1.3 x 15 Ø 3 x 40 B 107 0 565 080 Ø 1.3 x 15 Ø 3 x 40 B 151 0 565 081 Ø 1.7 x 4 Ø 1.5 x 15 Ø 3 x 40 B 76 0 565 082 Ø 1.4 x 15 Ø 3 x 40 B 107 0 565 083 Ø 1.4 x 15 Ø 3 x 40 B 151 0 565 084 CBN grinding points, solid tungsten carbide The new boron nitride grinding points made from solid tungsten carbide convince through their high rigidity and the resulting precise true running. They are available in ascending increments of 1/10 mm with a head diameter from 0.4 to 3.0 mm. All measurements in mm Suitable for every measure! These grinding points are available in increments of 1/10 mm between 0.4 and 3.0 mm diameter. You are sure to find the right one for your application!
