326 3 D T L1 d T D T D 3,0 6,0 Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 3. Diamond and CBN tools // 3.1. Diamond and CBN grinding points CBN grinding points shank Ø 3 mm Vrecom. wet = 30 m/s • Vrecom. dry = 20 m/s max. • max. extension length = 0.5 x L CBN grinding points, galvanic bonding, shank Ø 3 mm Head dimensions D x T Neck dimensions d x L1 Shank Ø x total length Grit size Order No. Price from 5 pieces Price from 1 piece Cylinder Ø 0.4 x 2 Ø 0.3 x 5 Ø 3 x 46 B 46 0 565 304 Ø 0.5 x 2 Ø 0.4 x 5 Ø 3 x 46 B 46 0 565 305 Ø 0.6 x 2 Ø 0.5 x 5 Ø 3 x 46 B 64 0 565 306 Ø 0.8 x 2 Ø 0.6 x 7 Ø 3 x 46 B 91 0 565 309 Ø 0.8 x 2 Ø 0.4 x 7 Ø 3 x 46 B 126 0 565 308 Ø 1 x 2 Ø 0.8 x 7 Ø 3 x 46 B 91 0 565 311 Ø 1 x 2 Ø 0.6 x 7 Ø 3 x 46 B 126 0 565 310 Ø 1 x 5 Ø 0.6 x 10 Ø 3 x 55 B 126 0 565 801 Ø 1.5 x 5 Ø 1.2 x 12 Ø 3 x 55 B 91 0 565 316 Ø 1.5 x 5 Ø 1.1 x 12 Ø 3 x 55 B 126 0 565 315 Ø 2 x 5 Ø 1.7 x 12 Ø 3 x 55 B 91 0 565 321 Ø 2 x 5 Ø 1.6 x 12 Ø 3 x 55 B 126 0 565 320 Ø 2 x 5 Ø 1.5 x 12 Ø 3 x 55 B 181 0 565 319 Ø 2.5 x 5 Ø 2.2 x 16 Ø 3 x 55 B 91 0 565 326 Ø 2.5 x 5 Ø 2.1 x 16 Ø 3 x 55 B 126 0 565 325 Ø 2.5 x 5 Ø 2.0 x 16 Ø 3 x 55 B 181 0 565 324 Ø 3 x 5 Ø 2.7 x 16 Ø 3 x 55 B 91 0 565 331 Ø 3 x 5 Ø 2.6 x 16 Ø 3 x 55 B 126 0 565 330 Ø 3 x 5 Ø 2.5 x 16 Ø 3 x 55 B 181 0 565 329 Ø 3.5 x 5 - Ø 3 x 55 B 91 0 565 336 Ø 3.5 x 5 - Ø 3 x 55 B 126 0 565 335 Ø 3.5 x 5 - Ø 3 x 55 B 181 0 565 334 Ø 4 x 5 - Ø 3 x 55 B 91 0 565 341 Ø 4 x 5 - Ø 3 x 55 B 126 0 565 340 Ø 4 x 5 - Ø 3 x 55 B 181 0 565 339 Ø 4.5 x 5 - Ø 3 x 55 B 91 0 565 346 Ø 4.5 x 5 - Ø 3 x 55 B 126 0 565 345 Ø 4.5 x 5 - Ø 3 x 55 B 181 0 565 344 Ø 5 x 6 - Ø 3 x 55 B 91 0 565 351 Ø 5 x 6 - Ø 3 x 55 B 126 0 565 350 Ø 5 x 6 - Ø 3 x 55 B 181 0 565 349 Ø 6 x 6 - Ø 3 x 55 B 91 0 565 355 Ø 6 x 6 - Ø 3 x 55 B 126 0 565 354 Ø 6 x 6 - Ø 3 x 55 B 181 0 565 353 All measurements in mm
