3 325 3,0 6,0 3. Diamond and CBN tools // 3.1. Diamond and CBN grinding points Diamond grinding points vacuum-brazed bonding shank Ø 3 and 6 mm Diamond grinding points vacuum-brazed bonding The new vacuum-brazed bonding provides a much better adhesion of grits to the carrier thanks to direct fusing. These tools are particularly suited for fibre glass reinforced materials GFK and CFK (in aircraft construction and shipbuilding), tungsten carbide green components (unsintered carbide), ceramics (i.e. valve covers for car engines), coal products (i.e. brake discs, carbon brushes), cast materials. Benefits of this new bonding: • Very good metal removal thanks to higher grain protrusion • Allows production of more complex forms, e.g. inner radius • Clearly better retention force of grit • Cooler grinding thanks to larger chipping spaces Diamond grinding points vacuum-brazed bonding, shank Ø 3 mm Head dimensions Angle Radius Shank Ø x total length Grit Order no. Price Cylinder Ø 7 x 7 - - Ø 3 x 55 D 427 0 563 037 Round cylinder Ø 4 x 7 - 2,0 Ø 3 x 55 D 427 0 563 038 Ø 6 x 10 - 3,0 Ø 3 x 55 D 427 0 563 039 Ball Ø 6 - - Ø 3 x 45 D 427 0 563 040 Ø 7 - - Ø 3 x 45 D 427 0 563 041 Pointed cone Ø 6 x 4 60° - Ø 3 x 55 D 427 0 563 035 Ø 6 x 10 30° - Ø 3 x 55 D 427 0 563 036 Round cone Ø 4/1 x 10 14° 0,5 Ø 3 x 55 D 427 0 563 033 Ø 6/3 x 10 20° 1,5 Ø 3 x 55 D 427 0 563 034 Ø 7/3 x 7 36° 1,5 Ø 3 x 55 D 427 0 563 032 Diamond grinding points vacuum-brazed bonding, shank Ø 6 mm Head dimensions Angle Radius Shank Ø x total length Grit Order no. Price Cylinder Ø 8 x 20 - - Ø 6 x 60 D 427 0 563 047 Ø 10 x 24 - - Ø 6 x 60 D 427 0 563 046 Round cylinder Ø 6 x 31 - 3.0 Ø 6 x 60 D 427 0 563 048 Ball Ø 6 - - Ø 6 x 60 D 427 0 563 051 Ø 8 - - Ø 6 x 60 D 427 0 563 050 Ø 12 - - Ø 6 x 60 D 427 0 563 049 Pointed cone Ø 9 x 4.5 90° - Ø 6 x 60 D 427 0 563 045 Ø 7 x 6 60° - Ø 6 x 60 D 427 0 563 044 Round cone Ø 6/1 x 19 15° 0.5 Ø 6 x 60 D 427 0 563 042 Flame Ø 8 x 14 - - Ø 6 x 60 D 427 0 563 043 NEW! Sets Diamond grinding points vacuum-brazed Shank dim. Order no. Setprice Diamond grinding points vacuum-brazed, 10 pieces Ø 3 x 55 mm 0 563 003 Diamond grinding points vacuum-brazed, 10 pieces Ø 6 x 60 mm 0 563 005
