323 3 D T R D T 2,35 3,0 6,0 Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 3. Diamond and CBN tools // 3.1. Diamond and CBN grinding points Diamond grinding points, galvanic bonding, shank Ø 6 mm Head dimensions D x T Neck dim. d x L1 Angle Radius R Shank Ø x total length Grit size Order No. Price from 5 pieces Price from 1 piece Trapez Ø 20.0 x 5.0 - 90° - Ø 6 x 45 D 91 0 560 952 Ø 20.0 x 5.0 - 90° - Ø 6 x 45 D 126 0 560 951 Ø 30.0 x 10.0 - 90° - Ø 6 x 50 D 91 0 560 955 Ø 30.0 x 10.0 - 90° - Ø 6 x 50 D 126 0 560 954 Round barrel Ø 6.0 x 20.0 - - - Ø 6 x 60 D 126 0 560 864 Ø 6.0 x 20.0 - - - Ø 6 x 60 D 181 0 560 863 Ø 10.0 x 15.0 - - - Ø 6 x 55 D 126 0 560 867 Ø 10.0 x 15.0 - - - Ø 6 x 55 D 181 0 560 866 Ø 15.0 x 30.0 - - - Ø 6 x 70 D 126 0 560 873 Ø 15.0 x 30.0 - - - Ø 6 x 70 D 181 0 560 872 Diamond grinding points shank Ø 6 mm Vrecom. = 15 - 20 m/s (head-Ø > 10 mm Vmax. = 20 m/s) • max. extension length 0.5 L, shank tolerance = h6, head tolerance = ± 0.2 mm All measurements in mm Also useful for any workplace: Protective goggles • clear, optically correct, scratchproof PC glasses • comfort cushions on the sidepiece ends • soft nose pad Cleaning fluid X 73016-A • ideal for cleaning moulds and workpieces • evaporates rapidly and without leaving residues • for all metals, glass, ceramics and almost all plastics Order No. Price 0 203 083 Order No. Price 0 580 521
