322
3
T
D
2,35 3,0 6,0
Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de
3. Diamond and CBN tools // 3.1. Diamond and CBN grinding points
Diamond grinding points
shank Ø 6 mm
Vrecom. = 15 - 20 m/s (head-Ø > 10 mm Vmax. = 20 m/s) • max. extension length 0.5 L, shank tolerance = h6, head tolerance = ± 0.2 mm
Diamond grinding points, galvanic
bonding, shank Ø 6 mm
Head dimensions
D x T
Neck dim.
d x L1
Angle Radius
R
Shank Ø x
total length
Grit
size
Order No. Price from
5 pieces
Price from
1 piece
Pointed cone (continued) Ø 6.0 x 18.0 - 20° - Ø 6 x 58 D 126 0 560 972
Ø 6.0 x 18.0 - 20° - Ø 6 x 58 D 181 0 560 971
Ø 6.0 x 12.0 - 30° - Ø 6 x 52 D 91 0 560 901
Ø 6.0 x 12.0 - 30° - Ø 6 x 52 D 126 0 560 900
Ø 6.0 x 12.0 - 30° - Ø 6 x 52 D 181 0 560 899
Ø 10.0 x 12.0 - 45° - Ø 6 x 52 D 91 0 560 976
Ø 10.0 x 12.0 - 45° - Ø 6 x 52 D 126 0 560 975
Ø 10.0 x 12.0 - 45° - Ø 6 x 52 D 181 0 560 974
Ø 18.0 x 15.0 - 45° - Ø 6 x 58 D 91 0 560 979
Ø 18.0 x 15.0 - 45° - Ø 6 x 58 D 126 0 560 978
Ø 18.0 x 15.0 - 45° - Ø 6 x 58 D 181 0 560 977
Ø 20.0 x 24.0 - 45° - Ø 6 x 64 D 91 0 560 982
Ø 20.0 x 24.0 - 45° - Ø 6 x 64 D 126 0 560 981
Ø 20.0 x 24.0 - 45° - Ø 6 x 64 D 181 0 560 980
Ø 10.0 x 9.0 - 60° - Ø 6 x 50 D 91 0 560 985
Ø 10.0 x 9.0 - 60° - Ø 6 x 50 D 126 0 560 984
Ø 10.0 x 9.0 - 60° - Ø 6 x 50 D 181 0 560 983
Ø 15.0 x 14.0 - 60° - Ø 6 x 54 D 91 0 560 988
Ø 15.0 x 14.0 - 60° - Ø 6 x 54 D 126 0 560 987
Ø 15.0 x 14.0 - 60° - Ø 6 x 54 D 181 0 560 986
Ø 20.0 x 18.0 - 60° - Ø 6 x 58 D 91 0 560 928
Ø 20.0 x 18.0 - 60° - Ø 6 x 58 D 126 0 560 927
Ø 20.0 x 18.0 - 60° - Ø 6 x 58 D 181 0 560 926
Ø 10.0 x 5.0 - 90° - Ø 6 x 45 D 91 0 560 931
Ø 10.0 x 5.0 - 90° - Ø 6 x 45 D 126 0 560 930
Ø 10.0 x 5.0 - 90° - Ø 6 x 45 D 181 0 560 929
Ø 20.0 x 10.0 - 90° - Ø 6 x 50 D 91 0 560 934
Ø 20.0 x 10.0 - 90° - Ø 6 x 50 D 126 0 560 933
Ø 20.0 x 10.0 - 90° - Ø 6 x 50 D 181 0 560 932
Ø 30.0 x 15.0 - 90° - Ø 6 x 55 D 91 0 560 937
Ø 30.0 x 15.0 - 90° - Ø 6 x 55 D 126 0 560 936
Ø 30.0 x 15.0 - 90° - Ø 6 x 55 D 181 0 560 935
All measurements in mm
