Diamond and boron nitride tools - joke Technology GmbH - #24

Text version of the page

321 3 D T D T D i 2,35 3,0 6,0 Bestseller! Tel. +49 (0) 22 04 / 8 39-0 • Fax +49 (0) 22 04 / 8 39-61 • info@joke.de 3. Diamond and CBN tools // 3.1. Diamond and CBN grinding points Diamond grinding points, galvanic bonding, shank Ø 6 mm Head dimensions D x T Neck dim. d x L1 Angle Radius R Shank Ø x total length Grit size Order No. Price from 5 pieces Price from 1 piece Ø 12.0 x 20.0 - - - Ø 6 x 60 D 91 0 560 841 Ø 12.0 x 20.0 - - - Ø 6 x 60 D 126 0 560 840 Ø 12.0 x 20.0 - - - Ø 6 x 60 D 181 0 560 839 Ø 15.0 x 6.0 - - - Ø 6 x 60 D 91 0 560 381 Ø 15.0 x 6.0 - - - Ø 6 x 60 D 126 0 560 380 Ø 15.0 x 6.0 - - - Ø 6 x 60 D 181 0 560 379 Ø 15.0 x 10.0 - - - Ø 6 x 60 D 126 0 560 846 Ø 15.0 x 10.0 - - - Ø 6 x 60 D 181 0 560 845 Ø 15.0 x 20.0 - - - Ø 6 x 60 D 126 0 560 849 Ø 15.0 x 20.0 - - - Ø 6 x 60 D 181 0 560 848 Sphere Ø 6.0 - - - Ø 6 x 60 D 91 0 560 889 Ø 6.0 - - - Ø 6 x 60 D 126 0 560 888 Ø 6.0 - - - Ø 6 x 60 D 181 0 560 887 Ø 8.0 - - - Ø 6 x 60 D 91 0 560 922 Ø 8.0 - - - Ø 6 x 60 D 126 0 560 921 Ø 8.0 - - - Ø 6 x 60 D 181 0 560 920 Ø 10.0 - - - Ø 6 x 60 D 91 0 560 892 Ø 10.0 - - - Ø 6 x 60 D 126 0 560 891 Ø 10.0 - - - Ø 6 x 60 D 181 0 560 890 Ø 15.0 - - - Ø 6 x 60 D 91 0 560 898 Ø 15.0 - - - Ø 6 x 60 D 126 0 560 897 Ø 15.0 - - - Ø 6 x 60 D 181 0 560 896 Ø 20.0 - - - Ø 6 x 60 D 91 0 560 925 Ø 20.0 - - - Ø 6 x 60 D 126 0 560 924 Ø 20.0 - - - Ø 6 x 60 D 181 0 560 923 Pointed cone Ø 6.0 x 55.0 - 6° - Ø 6 x 100 D 126 0 560 797 Ø 6.0 x 55.0 - 6° - Ø 6 x 100 D 181 0 560 798 Ø 6.0 x 42.0 - 8° - Ø 6 x 100 D 126 0 560 799 Ø 6.0 x 42.0 - 8° - Ø 6 x 100 D 181 0 560 800 Ø 6.0 x 33.0 - 10° - Ø 6 x 100 D 126 0 560 957 Ø 6.0 x 33.0 - 10° - Ø 6 x 100 D 181 0 560 956 Diamond grinding points shank Ø 6 mm Vrecom. = 15 - 20 m/s (head-Ø > 10 mm Vmax. = 20 m/s) • max. extension length 0.5 L, shank tolerance = h6, head tolerance = ± 0.2 mm please find more on page 322! All measurements in mm NEW! NEW!
